FPV Long Range Wireless Video Transmitter and Receiver with 5.8Ghz
Frequency and 9 Channels
Description:
If you are seeking an equipment that can transmit the audio and
video to a long distance without cable, for example the villa,
small lake, bridge or some other open areas, this transmitter
system is the right one you need.
This equipment will cover a long distance in the open area around
2500m, and 20km from air to ground. But when there are obstacle
between the transmitter and receiver, it will be decided case by
case.
This unit is the professional one and the signal is very strong in
5.8Ghz series that can be used to cover the long distance where
need strong signal and the industrial project.
Features:
· Wireless transmission: no need to set up communications cable
· Image, audio sync, color black and white compatible
· Small size, light weight, easy to carry, good installation
· Responsive, timely, send and receive real-time transmission
· Using FM mode, anti-interference ability, good image quality
· Highly integrated, stable and reliable transmission distance
· DC power supply, easy to use.
· Large output frequency, equipped fan in it, credibility, use for
long distance wireless transmit projects.
Specification:
Voltage | DC 12V |
Current | 700mA |
Frequency | 5.8Ghz |
Frequency Band | 5.72 GHz, 5.74 GHz, 5.76 GHz, 5.78 GHz, 5.80 GHz, 5.82 GHz, 5.84 GHz, 5.86 GHz, 5.88 GHz |
Number of channels | 9 channels |
Transmit Power | 1200mW |
Video Output | 1 Vp-p(FM) |
Audio Output | 1 Vp-p(FM) |
Audio Carrier Ware | 5.5M 6.0M |
Distance (Open environment) | 1000m-2500m |
Overall Configuration | Transmitter, receiver, AV cable, antenna |
Temperature | -10°C ~ +50°C |
Transmitter Weight | 65g |
Receiver Weight | 67g |
Whole Set Weight | 395g |
Dimensions (L * W * H) | Transmitter: 70*38*18.5mm. Receiver:72*43*11mm |
Box size (L * W * H) | 245*160*65mm |
