Customizable Aluminum Heatsink With Black Anodizing And Adjustable
Fin Height
Product Description:
With a Fin Height range of 5-50mm and Fin Thickness of 0.1-0.4mm,
this Skived Fin Heatsink is customizable to meet various cooling
requirements. The lightweight design of this heatsink allows it to
be used in applications where weight is a critical factor.
The Shaved-Fin Thermal Solution is highly efficient in dissipating
heat due to the large surface area provided by the skived fins. The
fins are made by shaving a block of Aluminum material, resulting in
a more precise and consistent fin shape and thickness. This process
allows for more fins per inch, which, in turn, increases the
surface area of the heatsink, providing higher cooling performance.
The Skived Fin Heatsink is an excellent choice for applications
that require high thermal conductivity and customizable cooling
solutions. It is ideal for use in high-power electronic devices
such as power supplies, LED lighting, and motor controllers. It can
also be used in medical equipment, telecommunication devices, and
automotive electronics.
In conclusion, the Skived Fin Heatsink is a highly efficient and
effective cooling solution that provides maximum thermal
performance. Its lightweight design, high thermal conductivity, and
customizable features make it an ideal choice for a wide range of
electronic applications. If you are looking for a reliable and
efficient cooling solution, the Skived Fin Heatsink is the perfect
choice for you.
Features:
- Product Name: Skived Fin Heatsink
- Thermal Resistance: 0.2-0.5°C/W
- Color: Black
- Thermal Conductivity: 226 W/mK
- Fin Density: 100-2000 Fins/inch
- Material: Aluminum
This Skived-Fin Thermal Solution provides efficient cooling with a
Thermal Conductivity of 226 W/mK. It has a Thermal Resistance of
0.2-0.5°C/W and a Fin Density of 100-2000 Fins/inch. The Skived-Fin
Cooling System is made of Aluminum and comes in black color. It is
a great Sliced-Fin Radiator option for heat dissipation in
electronics and other applications.
Technical Parameters:
| Product Attribute | Value |
| Product Name | Skived-Fin Cooling System |
| Thermal Conductivity | 226 W/mK |
| Application | Electronic Devices |
| Features | Lightweight, High Thermal Conductivity, Customizable |
| Base Thickness | 1-10mm |
| Base Size | 10-200mm |
| Fin Height | 5-50mm |
| Process | Skiving |
| Surface Treatment | Anodizing |
| Color | Black |
| Fin Thickness | 0.1-0.4mm |
Applications:
Whether you're looking to cool down a powerful CPU or keep your
industrial equipment running smoothly, the Sunmoral 1 Skived-Fin
Cooling System is the perfect solution. With a range of base sizes
from 10-200mm and a fin density of 100-2000 fins/inch, this product
is highly customizable to fit your specific needs.
Plus, with a sleek black anodized finish, this Skived-Fin Thermal
Solution not only performs well but looks great too. And, since
it's made in China, you can trust that it's built to last.
So, whether you're working on a personal computer build or a
large-scale industrial project, consider the Sunmoral 1 Skived-Fin
Cooling System for your thermal management needs. With its high
performance, customizability, and stylish design, it's the perfect
choice for any application.
