High Grade Neodymium Cylindrical Pot Magnets N35-N52 High Pull
Force
Product Description:
Our Neodymium Pot Magnets are made of Neodymium, coated with
Nickel, and have a tolerance of ±0.1mm. They are designed for axial
and thickness magnetic direction, and can be applied to a wide
range of applications. Our Neodymium Pot Magnets are available in
various sizes and shapes. The minimum order quantity is 100 pieces.
With superior magnetic properties and a strong construction, these
Neodymium Pot Magnets are ideal for industrial, commercial and
consumer applications.
Features:
- Product Name: Pot Neodymium Magnet
- Coating: Nickel
- Material: Neodymium
- Grade: N35-N52
- Tolerance: ±0.1mm
- Magnetic Direction: Thickness,Axial..
- Specialty: Neodymium Pot Magnets, Neodymium Pot, NdFeB Mounting
Magnet
Technical Parameters:
| Model | D (Mm) | D1 (Mm) | D2 (Mm) | H (Mm) | Hole Degree | Strength (Kg) |
| UN-A16 | 16 | 3.5 | 6.5 | 5 | 90° | 5 |
| UN-A20 | 20 | 4.5 | 8.6 | 7 | 90° | 6 |
| UN-A25 | 25 | 5.5 | 10.5 | 8 | 90° | 14 |
| UN-A32 | 32 | 5.5 | 10.5 | 8 | 90° | 25 |
| UN-A36 | 36 | 6.5 | 12 | 9 | 90° | 29 |
| UN-A42 | 42 | 6.5 | 12 | 9 | 90° | 37 |
| UN-A48 | 48 | 8.5 | 16 | 11.5 | 90° | 68 |
| UN-A60 | 60 | 8.5 | 16 | 15 | 90° | 112 |
| UN-A75 | 75 | 10.5 | 20 | 18 | 90° | 162 |
| UN-A90 | 90 | 10.5 | 20 | 18 | 90° | 300 |
| UN-A120 | 120 | 12.5 | 20.5 | 18 | 90° | 600 |
Applications:
UNMAG Pot Neodymium Magnets are produced with advanced rare earth
magnets with neodymium iron boron material, and have the features
of high performance, maximum magnetic energy, and high coercive
force. These Neodymium Pot Magnets are widely used for various
mounting and holding applications, such as motors, sensors,
displays, lifting, fixing, hanging and mounting. The UNMAG Pot
Neodymium Magnets come in grade N35 to N52, and are made with
tolerance up to ±0.1mm. The Pot Neodymium Magnets can be magnetized
in either axial or radial direction, and are packaged in carton
boxes for shipment. These Neodymium Pot Magnets are widely used in
various industries, such as medical, automotive, electronics,
aerospace, and others.
Customization:
Customized Pot Neodymium Magnet Services provided by UNMAG:
- Brand Name: UNMAG
- Place of Origin: China
- Pull Force: High
- Working Temperature: -20℃ To 80℃
- Tolerance: ±0.1mm
- Grade: N35-N52
- Material: Neodymium
- Products: Neodymium Hook, Shallow Pot Magnet, Neodymium Pot Magnets
Support and Services:
Technical Support and Service for Pot Neodymium MagnetWe provide technical support and service for Pot Neodymium Magnet.
Our team of technical experts is available to answer any questions
you may have about installation, operation, and maintenance of Pot
Neodymium Magnet.
We offer installation assistance and troubleshooting assistance for
Pot Neodymium Magnet. We can help you with any installation issues,
such as proper wiring connections, mounting, and other
installation-related problems.
We also offer maintenance and repair services for Pot Neodymium
Magnet. Our technicians can diagnose and repair any problems you
may have with your Pot Neodymium Magnet. We can also provide
periodic maintenance to ensure your Pot Neodymium Magnet is
functioning properly.
We also offer technical support by phone. Our customer service
representatives are available to answer any questions you may have
about installation, operation, and maintenance of Pot Neodymium
Magnet.
Please contact us if you have any questions or need any assistance
with your Pot Neodymium Magnet.
