    Parker 9109400 Suspension Air Spring Dunlop SP2334 Single Convoluted Air Actuator

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 1B4.5×1P
    Certification : ISO/TS16949:2009
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal or Others
    Supply Ability : 1000PCS/Week
    Delivery Time : 5-8 Working Days
    • Product Details
    • Company Profile

    Parker 9109400 Suspension Air Spring Dunlop SP2334 Single Convoluted Air Actuator

    Parker 9109400 Suspension Air Spring Dunlop SP2334 Single Convoluted Air Actuator


    Product Specifications


    Bottom Plate AlignmentParallel
    Bottom Plate Center To Center Diameter93 mm
    Bottom Plate Diameter110 mm
    Bottom Plate Hole Quantity6 pcs
    Bottom Plate TypeSteel
    Top Plate AlignmentParallel
    Top Plate Center To Center Diameter93 mm
    Top Plate Diameter110 mm
    Top Plate Hole Quantity7
    Top Plate TypeSteel
    Bellow Maximum Diameter125 mm
    Expanded Height125 mm
    Compressed Height45 mm
    Spring TypeSingle Convoluted
    Nut/Blind Nuts TypeM6
    Air Inlet3/8 BSP

    1B4.5×1P Refer Number


    Parker Air Spring

    9109400

    Firestone Air Spring

    W01-R58-4050, W01 R58 4050, W01R584050

    WO1-R58-4050, WO1 R58 4050, WO1R584050

    Dunlop Pneuride Air Spring

    4 1/2" x 1, 4 1/2' x 1, 4 1/2 x 1

    Dunlop Springride Air Spring

    SP2334, SP 2334

    Contitech Air Spring

    FS 44-5 DI, FS44-5 DI, FS 445 DI,

    FS 44 5 DI, FS44 5 DI, FS445 DI

    Norgren Air Spring

    PM/31041, PM31041, PM 31041


    Norgren Air Rubber Bellow We Can Supply


    6''×16''×2
    8''×18''×2
    10''×110''×2
    10''×312''×1
    12''×212''×3
    14 1/2''×114 1/2''×2
    14 1/2''×316''×2
    16''×321''×2
    26''×2

    Product Applications


    Rubber actuators, compared with traditional products (rigid actuators, spring...) offer numerous advantages such as

    • Flexibility (no angle or alignment problem)
    • Compactness
    • Power / price ratio
    • No maintenance or lubrication required
    • Durability
    • Reliability
    • Resistance to aggressive or hot conditions

    AIRSUSTECH rubber pneumatic tire is an indispensable accessory for self-powered type. Its main function is to reduce the working pressure of the pneumatic valve and stabilize it at a value, so that the door can obtain a stable pneumatic valve output power for adjustment and operation.


    1B4.5×1P Air Spring Detailed Pictures
