    30m Deep Solar Pile Driver Equipment With 25HP Diesel Engine

    Ask Lasest Price
    Brand Name : RanCheng
    Model Number : RCKM-30S
    Certification : CE, ISO 9001:2000
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 100sets per Month
    Delivery Time : 10-15 working days
    • Product Details
    • Company Profile

    30m Deep Solar Pile Driver Equipment With 25HP Diesel Engine

    2025 Hot Selling 30m Deep Solar Pile Driver Equipment With 25HP diesel engine

    Product Description

    The RCKM-30S Small Pile Driver Equipment is designed specifically for small pile projects, including photovoltaic solar pile drilling, soil nail pile drilling, earth screw pile drilling, ground auger pile drilling, and foundation mini pile drilling. This versatile machine is powered by a 25HP diesel engine and can drill to a maximum depth of 30 meters with a diameter range of 50-300mm.

    The equipment features a rubber crawler mounted walking system, ensuring easy movement across various terrains. It is equipped with hydraulic mechanical transmission, providing efficient power delivery and smooth operation.

    Ideal for on-site engineering projects, the RCKM-30S offers multi-angle piling, high precision, and strong durability. It is designed for efficiency, saving both time and labor, making it the perfect choice for small-scale pile driving projects. Its user-friendly design and strong adaptability ensure that operators can easily manage the machine in diverse working conditions, maximizing piling efficiency.

    Product Specifications

    ModelRCKM-30S
    Rig weight1.2t
    Dimensions (L×W×H)2300*1300*2200mm
    Engine power25HP
    Rotary head torque3500N.m
    Hydraulic oil pumpSingle pump
    hydraulic loading systemCylinder chain pressure
    Hydraulic working pressure20Mpa
    Way of walkingCrawler gearbox walking
    Walking speed7-15km/h
    cooling systemHydraulic cooler
    Carriage travel distance2.8m
    Piling height1-3m
    Borehole diameter50-300mm
    Borehole depth1-30m
    Air consumption6m3/min
    Adapt to rock typesMedium hard rock ,F=8-12
    Climbing ability35°
    Hydraulic legs4


    Product Features

    1.This machine is capable of drilling up to 30 meters deep with a diameter range of 50-300 mm, making it suitable for various pile-driving tasks.

    2.The drilling angle can be adjusted from 45° to 90°, providing flexibility for different drilling needs and ensuring efficient operation.

    3. Featuring a high-quality hydraulic system and reliable components, this machine is built to last and offers excellent performance over time.

    4. Equipped with a powerful hydraulic power head, it delivers fast drilling speeds and is capable of handling rock drilling with the included impactor.

    5. Powered by a trusted single-cylinder diesel engine, it offers strong performance and ensures stable operation for extended periods.

    6. Designed to move smoothly across a variety of challenging terrains without damaging the road surface, this machine provides excellent flexibility and maneuverability.

    Product Image


    Quality 30m Deep Solar Pile Driver Equipment With 25HP Diesel Engine for sale
