    1.2G 8dBi Directional Wifi PCB Antenna 1160MHz-1280MHz For Anti Drone Jammer

    Ask Lasest Price
    Brand Name : flysafe
    Price : Negotiable
    Delivery Time : 7-15 work days
    Payment Terms : LC,T/T
    • Product Details
    • Company Profile

    1.2G 8dBi Directional Wifi PCB Antenna 1160MHz-1280MHz For Anti Drone Jammer

    1.2G PCB 8dBi Antenna

    Product Description

    This set of 1.2G PCB 8dBi antenna for anti-drone jammer. Customers can customize the details of the antenna according to their needs and import it to their country more easily. It enhances signal transmission better compared to ordinary antennas. If the jammer is equipped with this antenna, it can provide better jamming effect.

    Product Paramenters

    Frequency Range
    1160-1280MHz
    Gain(dBi)
    8dbi
    VSWR
    ≤2
    Polarization
    Vertical
    Horizontal Beam width(0º)
    62-75º
    Vertical Beam width(0º)
    55-68º
    ( Front to back ratio)db
    8dB
    Input Impedance(Ω)
    50Ω
    Maximum input power(W)
    50W
    Input connector type
    SMA-J with 086 cable
    Lightning Protection
    DC Ground
    Dimensions­mm(Height/Width/Depth)
    96*81*1mm
    Antenna weight(kg)
    0.309Kg
    Rated Wind Velocity(m/s)
    60m/s
    Operational Humidity(%)
    10- 95
    Radome Color
    black
    Antenna body material
    Double-sided epoxy copper clad laminate
    Operating temperature(ºC)
    -40~55 º
    Installation Method
    Built-in installation
