Product Description:
The A520 Motherboard is a reliable and cost-effective platform
designed for everyday computing and light gaming. Supporting Ry
processors with the AM4 socket, this motherboard offers modern
connectivity options and efficient performance for a wide range of
users. It's ideal for those looking to build a durable and
future-ready PC without breaking the bank.
With support for high-speed DDR4 memory, PCIe 3.0, and advanced
storage options, the A520 Motherboard ensures smooth multitasking
and quick data access. Its compact form factor makes it suitable
for small and medium-sized PC builds, while its stable performance
and integrated features provide a seamless user experience.
Features:
1. **AM4 Socket**: Compatible with Ry 3rd Gen and 5th Gen
processors for powerful and energy-efficient performance.
2. **DDR4 Memory Support**: Supports up to 64GB of RAM, ensuring
smooth multitasking and faster application performance.
3. **PCIe 3.0 Slots**: Enables fast data transfer rates for
graphics cards and other expansion cards.
4. **M.2 and SATA III Support**: Offers multiple storage options,
including ultra-fast NVMe SSDs and traditional SATA drives.
5. **USB 3.2 Ports**: High-speed connectivity for external devices
and peripherals.
6. **Integrated Audio and LAN**: Ensures high-quality sound and
reliable wired internet connectivity.
7. **Compact Design**: Fits into various case sizes for flexible
build options.
8. **Fan Control Features**: Allows for optimized cooling and
reduced noise levels.
Parameter:
Chipset | AMD A520 chipset |
Processor Support | Support 3rd Gen AMD Ryzen™ 1000/2000/3000/4000/5000Series
Processors Support AMD AM4 Socket 1331 Processors |
LAN | Onboard Realtek8111H 1000Mbps LAN |
Memory Support | 2 x DDR4 DIMM Slots,
Support DDR4 2400/2666/2800/3200MHZ
Max. to 64GB
(For more information on compatible components, please check with
manufacturer) |
|
Storage | 4 x SATS 2.0 , Support AHCI
1 x M.2 Slot (Support 2242, 2280 M.2 SSD) |
|
USB | 6 x USB 3.0 ports(4 on the rear panel, 2 onboard pins)
4 x USB 2.0 ports(2 on the rear panel, 2 onboard pins) |
|
|
|
Back pane | 1 x Ps2 Port
1 x VGA Port
1 x HD Port
4 x USB 3.0 Ports
2 x USB 2.0 Ports
1 x RJ45 Port
1 x Audio Jacks(Line In / Line Out / MIC In) |
|
|
|
|
|
|
|
|
On-Board Pinheaders /Connectors | 1 x USB3.0 Pinheader
1 x USB2.0 Pinheader
1 x Front-Panel Audio Pinheader
1 x Front-Panel Pinheader
1 x Fan Connector
1 x 24-Pin ATX Power Connector
1 x 8-Pin ATX
1 x CLR_COM Pinheader
1 x SPEAK Pinheader |
|
|
|
|
|
Slots | 1 x PCI Express x16 Slot
1 x PCI Express x1 Slot |
|
Accessories | 1 x 4-pin SATA data cable
1 x I/O Backboard
1 x User Manual
1 x Drives installed CD |
|
Audio Interface | Realtek 6 channel HD audio |
Hot product:
Our advantages:
1. Original new card.
2. Support OEM&ODM,customization service.
3. We are the manufacturer, and the price will be the most
favorable.
4. We deliver quickly, and deliver within 3~7 working days after
placing an order.
5. Clients from 200＋ nations.
6. Focus on this market 20 yeas, Our experience and profession will
guarantee the purchase well
FAQ:
1. Product have warranty?
A: Yes, we provide after service. Please contact our professional
after-sales service.
2. How can we guarantee quality?
A: Always a pre-production sample before mass production; Always
final Inspection before shipment.
3. What can you buy from us?
A: Graphics cards,motherboard,RAM,Solid State Drive,HDD,CPU.etc.
Q: What service do you have?
A: Provide samples.
We also provide daily price list service. Please consult the
salesperson.
