RYH86Y Wall Mounted Carbon Dioxide Transmitter

RYH86Y wall-mounted carbon dioxide transmitter is suitable for measuring indoor carbon dioxide concentration. It can be installed in two ways: wall-mounted and 86 bottom box. It uses imported high-performance carbon dioxide sensor chips with high accuracy and good stability. It can be selected with or without display.

Basic parameters
Measuring medium	gas
Range	0-2000ppm, 0-5000ppm
Measurement accuracy	Range 0-2000ppm n400-2000ppm±(50ppm+5% of reading) Range 0-5000ppm n400-1000ppm±(50ppm+2.5% of reading) n1001-2000ppm±(50ppm+3% of reading) n2001-5000ppm±(40ppm+5% of reading)
Output signal	RS485
Supply voltage	24VDC±5%
Protection level	IP30
Warm-up time	＜180s
Response time	≤30s
Response frequency	≤2Hz
Resolution	1ppm
Overall weight	≈85g
Average current	≤60mA
Standby current	≤20mA
Environmental conditions
Ambient temperature	-10～60℃
Ambient humidity	0%～95%RH(no condensation, no condensation)
Electrical protection
Short circuit protection	permanent
Reverse polarity protection	No damage, but not working
Insulation resistance	≥100MΩ,500VDC
Dielectric strength	500VAC
Overall material
Main shell	ABS engineering plastics
show	LCD display without backlight
Output Limitation
RS485	0~2000/5000

manual
Product Information—Chinese (CN)	PDF
Product Information—English (EN)	PDF
Product Selection—Chinese (CN)	PDF
Product Selection—English (EN)	PDF
Installation Instructions—Chinese (CN)	PDF
Installation Instructions—English (EN)	PDF
Protocol Description—Chinese (CN)	PDF
Protocol Description—English (EN)	PDF
