5FT LED Linear Batten Light Fixture With Sensor , Wall Or Ceiling
Surface - Mounted Tri - Proof Fitting
This 5FT LED linear batten light fixture is a versatile and durable
solution, perfect for wall or ceiling surface mounting. With an
IP66 waterproof rating and IK10 impact resistance, it is ideal for
tri-proof applications in harsh environments. The integrated
microwave sensor allows for energy-efficient lighting control, and
its high-efficiency SMD2835 LED chips provide bright, uniform
illumination. Suitable for underground parking lots, workshops, and
basements, this fitting offers superior light distribution with its
milky PC diffuser.
Key Features:
Superior Durability: Rated IP66 and IK10, this fixture is both
waterproof and impact-resistant, ensuring reliable performance in
challenging conditions.
Energy-Saving Sensor: Equipped with a 5.8G microwave sensor that
offers 100%-20%-OFF dimming, reducing energy consumption when full
lighting isn't needed.
High Luminous Efficiency: Featuring 220lm/W SMD2835 LED chips, it
delivers high brightness with minimal energy use.
Quick and Easy Installation: Openable end cap design and push-type
terminal block allow for fast, tool-free wiring and installation.
Certified and Reliable: Backed by CE, ROHS, and SAA certifications,
this fixture comes with a 5-year warranty for peace of mind.
LED Linear Light Fixture(L-series) Parameter Data:
| Model | Input voltage | Watt | Sensor Dimming standby | Emergency |
| ZL-LSBLP18-2FT-CN | AC100V-240V | 18w | x | x |
| ZL-LSBLP36-4FT-CN | AC100V-240V | 36w | x | x |
| ZL-LSBLP44-5FT-CN | AC100V-240V | 44w | x | x |
| ZL-LSBLP18-2FT-DS | AC100V-240V | 18w | 100% / 20% /OFF | x |
| ZL-LSBLP36-4FT-DS | AC100V-240V | 36w | 100% / 20% /OFF | x |
| ZL-LSBLP44-5FT-DS | AC100V-240V | 44w | 100% / 20% /OFF | x |
| Note: x -No this function |
LED Linear Light Fixture(L-series) Specification:
| LUMINAIRE INFORMATION |
| Model | ZL-LSBLP18-2FT | ZL-LSBLP36-4FT | ZL-LSBLP44-5FT |
| Rated Power | 18W | 36W | 44W |
| Install | Surface Mount/Suspended/Linkable |
| Protection Rating | IP66 IK10 |
| Housing | PC+AL |
| Optics | PC Milky Diffuser |
| Connection Type | Quick Terminal Block(Push) or linkabke |
| Operating Temperature | -20℃ to 40℃ |
| Warranty | 3 Years |
| Dimming Option | Microwave Sensor - 3 Stepped Version(100%-20%-OFF) |
| PHOTOMETRIC |
| Luminous Efficacy | 110-130lm/W |
| LED | SMD2835 |
| CCT | 3000K/4000K/5000K/6000K |
| CRI | >80 |
| Beam Angle | 120 degree |
| ELECTRICAL |
| Input power Supply | AC220-240V/50-60HZ |
| Power Factor | 0.9 |
| Lifespan@Ta25°(L70) | 54,000 hours |
| Electrical Classification | Class II |
| Package Dimensions | 665*80*70mm | 1265*80*70mm | 1565*80*70mm |
