Brand Name : | Rexroth |
Model Number : | X771.32.0.1.AC.M2 |
Certification : | cc |
Price : | RMB/1000-10000/PC |
Payment Terms : | T/T |
Supply Ability : | 10PCS/days |
Delivery Time : | 3days |
Product Description
The Bosch Rexroth WE-1SP-M12X1 (R928028409) is a state-of-the-art electronic switching element designed to enhance the functionality of mechanical/visual maintenance indicators in hydraulic filter systems. This accessory can be easily attached to existing visual maintenance indicators using a locking ring, ensuring a secure fit without being influenced by the nominal pressure of the filter. The device operates by monitoring the back pressure or pressure differential in the system, which moves a piston against a spring. This action also shifts a solenoid that is mounted on the piston. The visual pin associated with this mechanism can display two positions: retracted when below nominal pressure and extended when exceeding nominal pressure. Notably, once extended due to pressure changes, the visual pin will remain in this position as an indication of system status, even after power is turned off or during a pressure drop, thanks to its cold start memory function. This feature requires manual acknowledgment to reset.
Incorporated within the WE-1SP-M12X1 are reed contacts that respond to magnetic field changes, allowing for precise operation with one or two switching points. The temperature suppression function ensures reliable performance by discharging excess temperature through the housing of the mechanical/visual indicator. It's important to note that this electronic switching element is not compatible with WOS.PA type indicators made from polyamide but offers modular flexibility and cold start signal suppression capabilities for other systems. While it comes with mating connector options (WESPMx), these connectors are not included with delivery. Alternatively, there is also a version available with plug-in connections (WESPEN). Overall, Bosch Rexroth's WE-1SP-M12X1 provides an advanced solution for monitoring and maintaining hydraulic systems efficiently and reliably across various applications where precise control and maintenance indication are crucial.
Brand | Rexroth |
Model | X771.32.0.1.AC.M2 |
Certifications | CE, UL, RoHS |
Communication Interface | CANopen |
Voltage | 24VDC |
Protection Class | IP20 |
Product Type | Driver Module |
Power Consumption | 240W |
Input Current | 0.5A |
Maximum Output Current | 10A |
FAQ
Q1: Wonder if you accept small orders?
A1: Do not worry. Feel free to contact us .in order to get more
orders and give our clients more convener ,we accept small order.
Q2: Can you send products to my country?
A2: Sure, we can. If you do not have your own ship forwarder, we
can help you.
Q3: What's your payment terms ?
A3: By T/T,LC AT SIGHT,100% full payment.
Q4: How long is your production lead time?
A4:It depends on product and order qty. Normally, it takes us 15
days for an order with MOQ qty.
Q5: When can I get the quotation ?
A5: We usually quote you within 24 hours after we get your inquiry.
If you are very urgent to get the quotation.Please call us or tell
us in your mail, so that we could regard your inquiry priority.
![]() |
