Marco Circular 4 Scissor Lift Table Stage Platform for Scene
Performances
Product DescriptionMarco Circular 4 Scissor Lift Table Stage Platform for Scene
Performances
| Mechanical data |
| Capacity | 2000 kg |
| Frame size | 1350 x 790 mm (x4) |
| Lift stroke | 900 mm |
| Lifting time | 39s |
| Closed height | 245 mm |
| Weight | 1680 kg |
Wooden floor will be placed on the circular platform so the table
can be used as a dance floor.Marco Standard ComponentsAll Marcolift standard lift tables are manufactured with high
quality components to enhance reliability, durability and safety in
operation.
| Pump | Bucher | Motor | Hoyer Denmark, protection IP55 |
| Control Panel | Marco standard control box | Sealing | Sweden, SKF |
| Cylinder | Marco, with rapture valve and damping | Limit switch | USA, Suns |
| Safety frame | Aluminum with limit switch | Scissor arm | Q345B, profile steel |
| Paint | Finland, Tikkurila | Hydraulic hose | USA, Eaton |
Marco Additional Component
In addition to the standard equipment of lift tables, it is
possible to provide Marcolift lift table with a range of
accessories to enhance safety, versatility, application and to
simply handling.
Packaging & Shipping:
Main Loading Port: ShangHai or Ningbo
Production Delivery: 6-8 weeks (public holiday excluded)
