Electric Bike Batteries: 36V Hailong Batteries (15Ah, 18Ah, 20Ah)
Introducing our high-performance 36V Hailong batteries, designed specifically for electric bikes:
Capacity Options: Available in 15Ah, 18Ah, and 20Ah to meet your energy needs and enhance performance.
Hailong Design: Sleek and compact, perfect for easy mounting on your e-bike for optimal balance.
Lithium Ion Technology: Provides reliable power, long lifespan, and improved safety compared to traditional batteries.
Lightweight Construction: Designed for easy installation without adding unnecessary weight to your bicycle.
Low Maintenance: Engineered for hassle-free operation, requiring minimal upkeep.
These 36V Hailong batteries are the ideal solution for powering your electric bike efficiently and reliably.
Feature:
High Quality Ebike Battery have excellent performance with diversity models. Long cycle life and safety during your usage.
– Capacity, Power, Voltage and Cell can be customized as your requirement for Min. sample order 1PCS.
– BMS protect battery no fire, no explosion, prevent over-discharge, over-charge, and short circuit. No safety risk.
– LED screen to monitor the battery pack energy status.
– Easy to remove, portable.
– Portable/Fashionable/Key control/Protection Board/Wonderful/Handle/Metal Case/Durable/Deep Cycle/Long Life Energy/Rechargeable/Safe memory effect/Low self discharge/High efficiency.
| Model | YW6-36V15AH | YW6-36V17.4AH | YW6-36V21AH | YW6-36V18AH | HS6-36V20.3AH | HS6-36V24.5AH |
| Configuration | 10S6P | 10S6P | 10S6P | 10S7P | 10S7P | 10S7P |
| Nominal voltage | 36V | 36V | 36V | 36V | 36V | 36V |
| Nominal capacity | 15AH | 17.4AH | 21AH | 18AH | 20.3AH | 24.5AH |
| Charge voltage | 42V | 42V | 42V | 42V | 42V | 42V |
| Standard charge current | ≤3(A) | ≤3(A) | ≤3(A) | ≤3(A) | ≤3(A) | ≤3(A) |
| Continuous discharge current | ≤20A | ≤20A | ≤20A | ≤20A | ≤20A | ≤20A |
| Discharge cut off voltage | 28V | 28V | 28V | 28V | 28V | 28V |
| Net weight | 4.0kg | 4.0kg | 4.0kg | 4.5kg | 4.5kg | 4.5kg |
| Case dimension | L370*W90* H113(mm) | L370*W90* H113(mm) | L370*W90* H113(mm) | L370*W90* H113(mm) | L370*W90* H113(mm) | L370*W90* H113(mm) |
| Cycle life | 800 times |
| Warranty | 1 year |
| BMS function | over-charge,over-discharge,over-current,short circuit |
| Fit motors | 250-500W |
| Charge temperature | 0 ~ 45°C |
| Discharge temperature | -20 ~ 60°C |
| Available colors | Black |
| Charge method | CC/CV |
| Charge port | DC |
Other Ebike Battery Models
FAQ
Q: What type of electric bike battery?
A: It is a Li-ion battery, Chemical is Li(NiCoMn)O2.
Q: What is the difference between a Li-ion battery,Ni-Mn battery and Lead acid battery?
A: E-bike Li-ion battery have longer cycle life,normal cycle life is 800-1000 times, and also with light weight,small size, No memory effect,Nontoxic, environmental friendly.
Q: What's the temperature range of charge and discharge?
A: Charge Temperature: 0 to 45°C and Discharge Temperature: -20 to 65°C
Q: What kind of cells are used on this electric bicycle battery?
A: Different capacities with different cells, we make the battery with original A grade Brand and high-quality domestic cells, all can be customized as your requests.
Q: Does your e-bike battery come with a charger?
A: All of our e-bike batteries come with charger.We have normal charger and fast charger. If you need fast charger please contact with us.
Q: Do your electric bike batteries come with BMS?
A: Yes, Our batteries all with SEIKO IC BMS, with stable performance.Which can protect the battery avoid short circuit,Overcharged,Over discharge and Over current.
Q: Can you provide OEM and ODM service?
A: Yes, We are a professional Electric Bike Battery manufacture with factory, which produce all kind of high quality E-bike lithium batteries as customers' requirements and designs, welcome to place OEM and ODM orders and visit our factory.
