    MF307EX– HIGH-PRECISION GYRO-BASED TRUE NORTH FINDER EMBEDDED CONTROL

    Ask Lasest Price
    Brand Name : RION
    Model Number : MF309
    Price : $8380.00/Pieces
    Payment Terms : T/T
    Supply Ability : 3000pcs per month
    Delivery Time : 4-6 weeks
    • Product Details
    • Company Profile

    MF307EX– HIGH-PRECISION GYRO-BASED TRUE NORTH FINDER EMBEDDED CONTROL

    MF307EX– HIGH-PRECISION GYRO-BASED TRUE NORTH FINDER EMBEDDED CONTROL


    1. Product Introduction

    Gyro North Finder is a high-precision autonomous orientation device designed to rapidly determine true north direction without external references. By measuring the Earth's rotational angular velocity through a sensitive gyroscope, it calculates the azimuth angle between the device's axis and geographic north, providing real-time heading data for carriers (e.g., vehicles, drones, or military systems).

    Key Advantages:

    • Autonomous Operation: No dependency on GNSS or magnetic fields.
    • High Accuracy: Compensates for environmental interference via multi-sensor fusion.
    • Rapid Alignment: Achieves north-seeking within minutes (specific time customizable).

    2. Product Composition

    As a compact electro-mechanical integrated system, the device includes:

    ComponentFunction
    High-performance GyroDetects Earth's rotation rate (e.g., fiber optic/MEMS gyro for <0.1° accuracy).
    AccelerometerMeasures tilt angles to correct horizontal alignment errors.
    Servo Rotation ModulePrecisely controls mechanical rotation to optimize signal collection.
    Embedded ComputerProcesses sensor data with Kalman filtering for real-time azimuth output.

    Optional Upgrades:

    • GNSS/INS integration for enhanced navigation.
    • Environmental shielding (temperature/vibration resistance).

    Technical Parameters:

    Parameters

    MF307EX

    North seeking time

    3 min / 2 min

    (adjustable)

    Range of tilt angles over which north can be found

    ±15°

    North seeking accuracy()

    0.5°

    Maintain heading

    (Zero bias stability 10s 1σ)

    3°/h

    Power supply

    9.5~36VDC (Attention: diameter of power supply line > 0.3mm2, power line and ground wire)

    Operating current

    Typical value: 0.5 A, maximum impact current: 1 A

    Interface

    TTL/RS232/RS422/RS485 optional

    Operating temperature

    -20℃~+50℃

    Storage temperature

    -40~+60℃

    Hot and humid environmental conditions

    Relative humidity less than 95%

    How it works

    Automatic self-check is started after power on, automatic north seeking is performed after the self-check is successful, and a north seeking result is sent to the upper computer after the north seeking is completed.

    Insulation resistance

    The insulation resistance between the independent circuits of the gyro north finder and between the circuit and the shell shall not be less than 10 MΩ under standard atmospheric conditions.

    MTBF

    ≥ 10000 hours

    MTTR

    ≤30min

    Material

    Stainless steel + aluminum alloy

    Weight

    ≤ 1.1 kg (excluding cable)

    COMPLETENESS REQUIREMENTS:

    The complete set of equipment includes:

    Product nameQuantityWeight

    gyroscope north finder

    1≤1.1kg
    Aviation plug cable (1m)1≤160g
