Product Description:
Our warehouses are made with high-quality materials that ensure
longevity and durability. The roof and wall cladding options
include EPS, Glass Wool, Rock Wool, and PU, providing excellent
insulation and protection against extreme weather conditions. The
roofing is available in sandwich panel or single steel sheet
options, ensuring maximum protection for your products.
We offer both bolt and weld connections, giving you the flexibility
to choose the option that works best for your business needs. The
door options include roller shutter and sliding doors, providing
easy access to your products.
At our Custom Steel Fabrication facility, we work with you to
create a warehouse that fits your specific needs. We understand
that every business is unique, and we strive to provide a solution
that meets your exact requirements.
|
main steel frame | H section steel beam and columns, painted or galvanized, galvanized
C section or steel pipe |
Secondary frame | hot dip galvanized C purlin , steel bracing , tie bar , knee brace
, edge cover etc. |
Roof panel | EPS sandwich panel,glass fiber sandwich panel,rock wool sandwich
panel,and PU sandwich panel or steel sheet |
Wall panel | Sandwich Panel or Corrugated Steel Sheet |
Tie Rod | Circular Steel Tube |
Brace | Round Bar |
Knee Brace | Angle Steel |
Roof Gutter | Color Steel Sheet |
Drawings & Quotation: |
(1) Customized design is welcomed. |
(2) In order to give you an exactly quotation and drawings, please
let us know the length, width, eave height and local weather.
We will quote for you promptly. |
Technical Parameters:
| Items | Specification |
| Main Steel Frame | Column | Q235, Q355 Welded H Section Steel |
| Beam | Q235, Q355 Welded H Section Steel |
| Secondary Frame | Purlin | Q235 C and Z purlin |
| Knee brace | Q235 Angle Steel |
| Tie Rod | Q235 Circular Steel Pipe |
| Brace | Q235 Round Bar |
| Vertical and Horizontal Support | Q235 Angle Steel, Round Bar or Steel Pipe |
| Maintenance system | Roof Panel | EPS Sandwich Panel /Glass Fiber Sandwich Panel / |
| Rock Wool Sandwich Panel / Pu Sandwich Panel /Steel Sheet |
| Wall Panel | Sandwich Panel / Corrugated Steel Sheet |
| Accessories | Window | Aluminium Alloy Window / PVC Window / Sandwich Panel Window |
| Door | Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door |
| Downspout | PVC |
| Live load on Roof | In 120kg/Sqm (Color steel panel surrounded) |
| Wind Resistance Grade | 12 Grades |
| Earthquake-resistance | 8 Grades |
| Structure Usage | Up to 50 years |
| Temperature | Suitable temperature.-50ºC~+50ºC |
| Certification | CE, SGS, ISO9001:2008, ISO14001:2004 |
| Finishing Options | Vast array of colors and textures available |
| Paint Options | Alkyd painting, two primary painting, two finish painting |
| (gray paint, red paint, white paint, epoxy zinc etc.) Or
Galvanized. |
Applications:
The roofing of the warehouse is made of Sandwich Panel or Single
Steel Sheet. The raw steel material used for the manufacturing is
Q235B and Q355B. The connection of the warehouse is either through
Bolt or Weld. The warehouse has a dual function, it can be used as
a workshop or a warehouse.
The Steel Structure Warehouse is an ideal product for different
occasions and scenarios. It can be used as a Cold Room Warehouse,
where the temperature is maintained at a low level, to store
perishable items such as fruits, vegetables, and dairy products.
The warehouse can also be used for Automated Warehouse Racking
Systems, where heavy goods can be stored and retrieved
automatically. Industrial Warehouse Shelving can also be installed
in the warehouse to store light to medium weight goods such as
electronics, clothing, and household items.
Support and Services:
Our Steel Structure Warehouse product comes with comprehensive
technical support and services to ensure that your project is
successful. Our team of experts can provide:
- Structural design and engineering services
- Site planning and preparation services
- Installation and construction services
- Project management services
- Maintenance and repair services
We are committed to providing top-notch customer service and
support throughout the entire project process. Our team is
available to assist with any questions or concerns you may have
about the Steel Structu
re Warehouse product and its installation.
Packing and Shipping:
Product Packaging:
- All steel components are securely packed in wooden or steel pallets
to prevent damage during transportation.
- Roof and wall panels are wrapped in plastic film to protect against
scratches and dirt.
- Small parts are packed in a separate box and labeled for easy
identification during installation.
Shipping:
- The steel structure warehouse is shipped in containers or as bulk
cargo, depending on the size and quantity of the components.
- Transportation is arranged by the supplier and delivery times vary
depending on the destination and mode of transportation.
- Customers are responsible for unloading the cargo at the
destination and should have the necessary equipment and personnel
to do so.
FAQ:
Q:Are you manufacturer or trading company?
A:We are manufacture factory, located in Qingdao city, near to
Qingdao port. And we have total 3 workshops from steel structure to
wall and roof sheet.
Q: How about your quality control?
A: We have got certificate ISO & CE. Products processing through
cutting, bending, welding, shot blasting, ultrasonic testing,
packing, storing, loading to ensure no quality defects.
Q: Is third party inspection available?
A: SGS, BV, TUV, etc. are available, it is according to client
requirement.
Q: How about your delivery time?
A: Generally within 30-45 days, it is according to order quantity,
partial shipment is allowed for big order.
Q: What about the installation?
A: We'll provide the detailed installation drawing, supervisors
guiding installation is available. We can do turnkey job for some
kind of projects.
Q: How to ensure the product you supply is what we want exactly?
A: Sales and engineer team will provide you the suitable solution
according to your requirements before placing order. Proposal
drawing, Shop drawing, 3D drawing, Materials photos, Finished
projects photos are available, which will help you understand the
solution we provided deeply.
