Product Description:
Pneumatic valve positioner: The reference variable for this positioner is the standard
pneumatic signal ranging from 0.2 to 1 bar. It is an ideal option
for accurately controlling different pneumatic regulating valves.
Electric/gas valve positioner: This positioner is designed for industrial applications that
require high precision control. It accepts input control signals
ranging from 4 to 20 mA.
Electric valve positioner: This positioner is integrated into the electric actuator and comes
equipped with a built-in control algorithm to provide stable
performance. It is perfect for long-term and stable operation.
Features:
The air capacity of this product is high and it offers simple
attachment to common linear and rotary actuators. It can be
directly attached to SAMSON, NAMUR rib, rod-type yokes according to
IEC 60534-6-1, rotary actuator attachment according to VDI/VDE
3845, and attachment according to VDI/VDE 3847.
Position sensing is non-contact while the device offers plain-text
display with NAMUR Recommendation NE 107 states and messages. It
also has integrated diagnostic functions and can be operated easily
with a one-knob, menu-driven operation. The LCD screen can be
easily read in any mounting position thanks to the selectable
reading direction.
It can be configured with a computer over the SSP interface using
the TROVIS-VIEW software. It also has variable automatic start-up
with four different initialization modes. In case of emergency, it
offers sub (substitution) initialization mode for the positioner to
be started up without having to change the valve position.
All parameters are saved in non-volatile EEPROM while it operates
on a two-wire system with a small electrical load of 465 Ω. It also
offers adjustable tight-closing function and continuous zero
monitoring.
Technical Parameters:
| Product Attribute | Value |
| Brand Name | SAMSON |
| Valve Positioner | Yes |
| Control Positioner Actuator | Yes |
| Valve Position Regulator | Yes |
| Opening Angle | 24 to 100° |
| Approximate Weight | 3.5 Kg (8.0 Pounds) |
| Static Destruction Limit | 40 V, Internal Current Limit Approx. 40 mA |
| Direction of Action | Reversible |
| Travel Range | Adjustable Within The Initialized Travel/angle Of Rotation Of The
Valve; Travel Can Be Restricted To 1/5 At The Maximum |
| Operating Temperature | Standard Temperature, High Temperature |
| CONTROL LOOP | 4 to 20 MA |
| Sensitivity | ≤0.1 % |
| Valve Travel | 3.6 to 300 mm |
Applications:
SAMSON is a renowned German company that has been producing high
quality valve positioners for over 90 years. Their valve positioner
series includes pneumatic valve positioners, electric/gas valve
positioners, and electric valve positioners. These positioners are
widely used in various industries such as petrochemical, electric
power, light industry, metallurgy, medicine, beer and beverage, and
city heating.
SAMSON is known for its commitment to producing high quality
products that meet the evolving needs of their customers. Their
valve positioners are built to the highest technical and safety
standards, ensuring optimal efficiency and accuracy in controlling
valve positions.
SAMSON's entrepreneurial spirit and innovative approach have made
them pioneers in the valve positioner industry. Their dedication to
research and development has led to the creation of innovative
products that are trusted by industry professionals worldwide.
Support and Services:
Our Control Valve Positioner product is designed to ensure precise
control of valve positioning in a variety of industrial
applications. We offer comprehensive technical support and services
for this product, including:
- Installation assistance
- Calibration and testing services
- Repairs and maintenance
- Technical troubleshooting and problem-solving
- Training and education for optimal product use
Our experienced technicians and engineers are available to provide
expert assistance and guidance at every stage of your Control Valve
Positioner product's lifecycle. We are committed to ensuring the
reliable and efficient operation of your equipment, and will work
with you to minimize downtime and maximize productivity.
