    SUN Cartridge Valve FPCC-XDN Adjustable Dither And Current Sensing For Optimum Performance

    Ask Lasest Price
    Brand Name : SUN
    Model Number : FPCC-XDN
    Certification : cc
    Price : RMB/1000-10000/PC
    Payment Terms : T/T
    Supply Ability : 10PCS/days
    Delivery Time : 3days
    • Product Details
    • Company Profile

    SUN Cartridge Valve FPCC-XDN Adjustable Dither And Current Sensing For Optimum Performance

    Product Description


    This valve is a normally closed, electro-proportional throttle that is spring-biased closed. Energizing the coil generates an opening force on the spool proportional to the command current, and this force is countered by the spring and flow forces. This force balance creates a metering orifice whose effective size is proportional to the current. The valve exhibits a large degree of self-compensation in the 1-to-2 direction and will provide proportional flow control in the 2-to-1 direction with the addition of an external compensator. Full reverse flow (2-to-1) with 100% command in the 2-to-1 direction is possible without a compensator under all conditions.Available in either a normally open or normally closed configuration with three different capacity ranges.Capable of operating with pressures up to 5000 psi (350 bar).Low leakage levels in the closed position.


    Coils are interchangeable with Sun's other full flow, solenoid-operated valves and can be mounted on the tube in either direction.This cartridge has several manual override choices, including no manual override. See Option Configuration.For optimum performance, an amplifier with current sensing and adjustable dither should be used. Dither should be adjustable between 100 - 250 Hz.On models equipped with the D or L control, the detent mechanism in the manual override is meant for temporary actuation. The D, E, L and T manual control assemblies have a mechanical life expectancy of approximately 7,000 cycles.The momentary/twist override option "E" allows the operator to shift the valve by twisting the manual override clockwise 90 degrees.Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.


    BrandSUN
    ModelFPCC-XDN
    Maximum Temperature250°F
    Maximum Flow30 GPM
    Port TypeNPTF
    MediaHydraulic Oil
    Max Back Pressure3000 PSI
    Coil Power10 Watts
    FunctionPressure Relief
    Leakage Rate0 drops/min at 5000 PSI


    FAQ


    Q1: Wonder if you accept small orders?
    A1: Do not worry. Feel free to contact us .in order to get more orders and give our clients more convener ,we accept small order.


    Q2: Can you send products to my country?
    A2: Sure, we can. If you do not have your own ship forwarder, we can help you.


    Q3: What's your payment terms ?
    A3: By T/T,LC AT SIGHT,100% full payment.


    Q4: How long is your production lead time?
    A4:It depends on product and order qty. Normally, it takes us 15 days for an order with MOQ qty.


    Q5: When can I get the quotation ?
    A5: We usually quote you within 24 hours after we get your inquiry. If you are very urgent to get the quotation.Please call us or tell us in your mail, so that we could regard your inquiry priority.
