Product Description:
This oil-lub screw Compressor is specifically designed to deliver
reliable and consistent performance, thanks to its advanced cooling
system that ensures temperature stability even during continuous
operation. The air cooling system ensures maximum performance and
efficiency, making it ideal for use in demanding industrial
environments.
The Rotary-screw Compressor is built with high-quality materials
and advanced technology to ensure durability and long-lasting
performance. It features a simple, user-friendly design that makes
it easy to operate and maintain, while also providing excellent
energy efficiency and cost savings.
The inlet pressure of the Rotary-screw Compressor is set at
atmospheric pressure, making it easy to integrate into a wide range
of industrial applications. It is designed to be easy to install
and operate, with a compact footprint that saves valuable space in
your workshop or factory.
Whether you need a reliable compressor for use in a small workshop
or a large industrial facility, the Oil Injected Screw Compressor
is an excellent choice. With its advanced technology, high-quality
construction, and efficient performance, it provides the perfect
combination of reliability, performance, and cost-effectiveness.
Features:
- Product Name: Air Cooling Compressor
- Type: Rotary-screw Compressor
- Cooling type: Air Cooling
- Power Source: Electric
- Lubricating oil volume: 30L
- Features:
- Efficient rotary-screw compressor design
- Lubricated screw compressor
- High quality air output
- Quiet operation
- Easy to install and maintain
- Compact size
- Reliable performance
Technical Parameters:
| Technical Data of Rotorcomp LGSD(C) series Screw Air Compressor | | ITEM | UNIT | MODEL | | | LGSD-37 | | Compressor | | ¹ Capacity (f.a.d.) at gauged pressure | m3/min | 6.7 | 6.6 | 5.8 | | Max. working pressure | MPa | 0.7 | 0.8 | 1 | | Compressor type | | Oil inject screw compressor | | Cooling type | | Air cooling | | Driven type | | Direct driven | | Inlet status | Temperature | ℃ | ≤45 | | Pressure | MPa | Atmospheric pressure | | Relative humidity | | ≤90% | | Cooling air flow | m3/hr | 9200 | | Control mode | | Intelligent controller | | Safety valve set pressure | MPa | 0.77 | 0.88 | 1.1 | | Lubricating oil volume | L | 25 | | Lubricating oil brand | | ROTORCOMP | | Drive rotor speed | rpm | 2940 | | Main Motor | Rated Power | KW | 37 | | Type | | Fix speed | | Speed | rpm | 2940 | | Service factor | | 1.2 | | Protection type | | IP55 | | Insulation class | ISO | F | | Efficiency | | IE3 | | Startup mode | | ʏ-Δ starting | | Voltage(Special on request) | V | 380 | | Frequency(Special on request) | Hz | 50 | | Rated current | A | 67.41 | | Fan Motor | Rated Power | KW | 1.5 | | Type | | Fix speed | | Speed | rpm | 1480 | | Protection type | | IP55 | | Insulation class | ISO | F | | Startup mode | | Direct starting | | Voltage(Special on request) | V | 380 | | Frequency(Special on request) | Hz | 50 |
|
|---|
Applications:
One of the key advantages of the shanghai rotorcomp Rotary-screw
Compressor is its air-cooled design. This means that you don't need
to worry about water cooling or other complex systems - simply plug
it in and you're good to go. With a free air delivery of up to
0.92/0.87/0.75/0.61-13.6/13.00/11.50/9.80 M³/Min, this compressor
is more than capable of handling even the most demanding
applications.
The shanghai rotorcomp Rotary-screw Compressor is powered by a 380V
electric motor and features a belt-driven system for maximum
efficiency and reliability. This makes it the perfect choice for a
wide range of applications, from construction and manufacturing to
automotive repair and maintenance.
When you order your shanghai rotorcomp Rotary-screw Compressor, you
can expect it to arrive in a sturdy wooden case for maximum
protection during shipping. Delivery times typically range from
5-15 working days, and we offer a range of payment options
including TT, LC, D/A, D/P, and Western Union. And with a supply
capacity of 1,000 units per month, you can rest assured that we
have the resources to meet even the largest orders.
So why wait? If you're in the market for a high-quality
Rotary-screw Compressor, look no further than shanghai rotorcomp.
Contact us today to learn more about our products, pricing, and
delivery options!
FAQ:
Q: What is the brand name of this Screw Air Compressor?
A: The brand name of this compressor is shanghai rotorcomp.
Q: What is the model number of this Screw Air Compressor?
A: The model number of this compressor is LGCD-5.5-75kw.
Q: Where is this Screw Air Compressor manufactured?
A: This compressor is manufactured in China.
Q: Is this Screw Air Compressor certified?
A: Yes, this compressor is certified with ISO, CE, and TUV
certifications.
Q: What is the minimum order quantity for this Screw Air
Compressor?
A: The minimum order quantity for this compressor is 1 unit.
Q: What is the price of this Screw Air Compressor?
A: The price for this compressor is negotiable.
Q: What are the packaging details for this Screw Air Compressor?
A: The compressor will be packaged in a wooden case.
Q: What is the delivery time for this Screw Air Compressor?
A: The delivery time for this compressor is 5-15 working days.
Q: What are the payment terms for this Screw Air Compressor?
A: The payment terms for this compressor include TT, LC, D/A, D/P,
and Western Union.
Q: What is the supply ability for this Screw Air Compressor?
A: The supply ability for this compressor is 1,000 units per month.
