| Brand Name : | GCL |
| Model Number : | Ggalaxy |
| Certification : | EMC/CE/ROHS/CCC/FCC/BIS |
| Price : | Negotiable |
| Supply Ability : | 5000 Square Meter/Square Meters per Month |
| Delivery Time : | 15-20Days |
500*500mm Indoor Full Colour P1.95 P2.5 mm Video Wall Led Display
Screen
Product features:
Easy Installation Without Steel Structure
The small-sized screens eliminate the need for a steel frame,
featuring lightweight and convenient characteristics.
Effortless wall mounting, saving on project structural costs and
installation space.
Wide Viewing Experience:
With a horizontal viewing angle of 160° and a vertical viewing
angle of 140°, the display allows for a clear view of the content
from multiple angles; the surface flatness of the display screen is
within ≤1mm.
High Definition And High Refresh Rate
The 7680Hz high refresh rate display technology effectively reduces
screen flicker, protecting viewers' eyes and providing a smoother
visual experience for optimal viewing.
Lightweight and easy to install:
The lightweight die-cast aluminium casing is as thin as 8mm, and
the internally curved handle design facilitates convenient
installation.
Wall-Mount Installation:
The lightweight design of the unit allows small screens to be
easily mounted on the wall without a heavy steel frame, saving both
costs and installation space.
Modular design for easy maintenance:
specifically designed for wall-mounted projects, it eliminates the
need for a dedicated maintenance passage. Maintenance can be easily
performed by removing just two screws, allowing the power box to be
detached effortlessly for servicing.
Parameters of Ggalaxy Series:
| Product | P1.953 | P2.5 | P2.604 | P2.976 | P3.91 |
| Pitch | 1.953mm | 2.5mm | 2.604mm | 2.976mm | 3.91mm |
| Density(pixels/m²) | 262144 | 160000 | 147456 | 112896 | 65536 |
| LED Type | SMD1212 | SMD1515 | SMD1515 | SMD2020 | SMD2020 |
| Brightness | 700nits | 800nits | 800nits | 800nits | 800nits |
| Scan Method | 1/32 | 1/25 | 1/32 | 1/28 | 1/16 |
| Panel Size | 500×500mm | ||||
| Module Size | 250×250mm | ||||
| Panel Material | Die-casting Aluminum | ||||
| Panel Weight | 8kg | ||||
| Protection Level | IP31 | ||||
| Maintenance | Module Front Service &Rear Service | ||||
| Max Power Consumption | 450W/㎡ | 450W/㎡ | 450W/㎡ | 550W/㎡ | 550W/㎡ |
| Average Power Consumption | 150W/㎡ | 150W/㎡ | 150W/㎡ | 180W/㎡ | 180W/㎡ |
| Refresh Rate | 3840Hz | ||||
| Grey Scale | 13-16bit | ||||
| Viewing Angle | H160°,V140° | ||||
| Voltage | AC100~240V(50-60Hz) | ||||
| Working Temperature | -20℃ to 60℃ | ||||
| Working Humidity | 10%-90%RH | ||||
| Color Temperature | 3000-9500K | ||||
| Certifications | CE/ROHS/EMC/TUV/UL/CCC/FCC/ISO | ||||





|
