445W Optimized Monocrystalline Silicon Panels for Commercial and Utility-Scale Projects

445W Optimized Monocrystalline Silicon Panels for Commercial and Utility-Scale Projects

Product Description:

This 182 P-type Bifacial Module offers a robust solution for those seeking high power output with excellent efficiency. With a power range of 445W to 460W and a maximum efficiency of 21.25%, it is optimized for bifacial applications, allowing for additional energy generation from both sides of the panel.

Electrical Performance Parameters |STC
Model Type		445D(HBD) 60(182)	450D(HBD) 60(182)		455D(HBD) 60(182)	460D(HBD) 60(182)
Nominal Max.Power	Pmax(W)	445	450		455	460
Max.Power Voltage	Vmp(V)	34.58	34.78		34.98	35.18
Max.Power Current	Imp(A)	12.87	12.94		13.01	13.08
Open Circuit Voltage	Voc(V)	41.08	41.20		41.32	41.46
Short Circuit Current	Isc(A)	13.76	13.83		13.90	13.97
Module Efficiency	(%)	20.56	20.79		21.02	21.25
Power Output Tolerance	(W)	0~+5W
*STC:Irradiance 1000W/m²,Cell Temperature 25℃,Air Mass AM1.5. *Power measurement tolerance ±3%.
Electrical Performance Parameters |NMOT
Model Type		445D(HBD) 60(182)	450D(HBD 60(182)		455D(HBD) 60(182)	460D(HBD) 60(182)
Nominal Max.Power	Pmax(W)	317	322		327	332
Max.Power Voltage	Vmp(V)	30.54	30.91		31.27	31.62
Max.Power Current	Imp(A)	10.38	10.42		10.46	10.50
Open Circuit Voltage	Voc(V)	38.78	38.90		39.02	39.14
Short Circuit Current	Isc(A)	11.11	11.17		11.22	11.28
*NMOT:Iradiance 800W/m²,Cell Temperature 20℃,Wind Speed 1m/s *Power measurement tolerance ±3%.
Structure Performance
Solar Cell Type		182mm Mono-crystalline (Half Cell)
Solar Cell Arrangement		120pcs(6×20)
Module Dimension		1909×1134×35mm/30mm
Weight		26.9kg(35mm)/25.7kg(30mm)
Front Glass		2.0mm,highly transparent tempered glass with anti-reflective coating
Frame		Anodized Aluminum Alloy
Junction Box		IP68 rated
Cable		4mm²,portrait m(-()+)la cano 9 1 m( )(- Lengthcan be customized
Diode Quantity		3 pcs
Front side/Rear side		5400pa/2400pa
Connector		MC4 Compatible
Per Pallet		31pcs(35mm)/36pcs(30mm)
Per Container(40'HQ)		744pcs(35mm)/864pcs(30mm)

Application:

Suitable for commercial and utility-scale projects where maximizing energy yield is a priority. This bifacial module is especially effective in environments with high albedo, such as deserts or snowy regions, where the additional rear-side energy generation can be fully utilized.
