Cnc Swiss Lathe Machining Sm325 Fanuc Controller Turning With Auto
Bar Feeder
Product Description: Cnc Swiss Lathe Machining Sm325 Fanuc Controller Turning With Auto
Bar Feeder
Sm325 Characteristics of Machine Tool Our perfect entry-level model
for the highly flexiblemanufacture of complex parts.Simultaneous
machining up to
3 tools for maximumproductivity and efficiency
Features: Cnc Swiss Lathe Machining Sm325 Fanuc Controller Turning With Auto
Bar Feeder
Double spindle
1.Thismachineadoptsdual-spindle,closed-loopprocessing.which
hasstablerigidity and improved efficiency.
2.Thedual spindlescanprocesscomplexworkpieces andcomplete them
atone time,which improves theprocessability.
3.InternalFigure :Maximumclampingofthemainshaftis 32mm,which is
convenient for processing of loose parts orrear loading.
4.Thedual spind lescan process complex workpieces and complete them
atone time,which improves theprocessability.
5.Internal Figure :Maximum clamping of the main shaft is 32mm,which
is convenient for processing of loose parts orrear loading.
6.The clamping rangeis 5-32mm.the collet
modelisA2-5,additionalcollet.
Technical Parameters:
| Describe |
Unit |
Specifications |
| Processing capacity | Max machining diameter | mm | ￠32 |
| Stroke | mm | 280 |
| Main Spindle RPM | rpm | 8000 |
| Sub Spindle RPM | rpm | 8000 |
| Cross Driven Tools RPM | rpm | 5000 |
| Main/Sub Spindle CS axis indexing minimum unit | ° | 1/1000(0.001) |
| Rapid Traverse Rate | X1/Z1 axis | m/min | 24 |
| Y/X2/Z2 axis | m/min | 32 |
| Arrangement of tools | O.D Tools | ea | 6 |
| Front Work Tools | ea | 5 |
| Cross Driven Tools | ea | 4 |
| Back end tools 4 axis(fixed) | ea | 4(fixed) |
| O.D Tools specification | mm | □16×16 |
| Front Work Tools diameter | mm | ￠20 |
| Power Tool Chuck Specifications | mm | ER16 |
| Motors | Spindle motor | kw | 5.5/7.5 |
| Sub Spindle motor | kw | 1.5/2.2 |
| Servo axis motor | kw | 0.75 |
| Cross Driven Tools motor | kw | 0.55/1.1 |
| Lubrication pump motor | w | 100 |
| Coolant motor | kw | 0.9 |
| Others | Coolant tank capacity | L | 200 |
| Lubrication tank capacity | L | 1.8 |
| Height from floor to spindle center | mm | 1000 |
Floor space | (L) | mm | 2581 |
| (W) | mm | 1563 |
| (H) | mm | 1791 |
| Mass of machine | kg | 3800 |
| CNC control unit | Set | FANUC oi TF-PLUS |
Applications:
Automobile parts: Injector nozzles,Oil pump shaft, Short tube shaft of automatic
transmission gear
Cylinder cylinder parts, ABS system parts.
Medical components: hollow screws, spinal screws, locking screws, dental screws, and
medical devices.
Electronic components: RF connectors, pins, motor shafts, inner conductors
