DOW Ultrafiltration Membrane Modules SFP-2660 / SFD-2660 PVDF 0.03 µm 1.3 – 4.0 m3/hr

    Buy cheap DOW Ultrafiltration Membrane Modules SFP-2660 / SFD-2660 PVDF 0.03 µm 1.3 – 4.0 m3/hr from wholesalers

    Buy cheap DOW Ultrafiltration Membrane Modules SFP-2660 / SFD-2660 PVDF 0.03 µm 1.3 – 4.0 m3/hr from wholesalers
    • Buy cheap DOW Ultrafiltration Membrane Modules SFP-2660 / SFD-2660 PVDF 0.03 µm 1.3 – 4.0 m3/hr from wholesalers
    • Buy cheap DOW Ultrafiltration Membrane Modules SFP-2660 / SFD-2660 PVDF 0.03 µm 1.3 – 4.0 m3/hr from wholesalers
    • Buy cheap DOW Ultrafiltration Membrane Modules SFP-2660 / SFD-2660 PVDF 0.03 µm 1.3 – 4.0 m3/hr from wholesalers
    • Buy cheap DOW Ultrafiltration Membrane Modules SFP-2660 / SFD-2660 PVDF 0.03 µm 1.3 – 4.0 m3/hr from wholesalers

    DOW Ultrafiltration Membrane Modules SFP-2660 / SFD-2660 PVDF 0.03 µm 1.3 – 4.0 m3/hr

    Ask Lasest Price
    Brand Name : DOW
    Model Number : SFP-2660 / SFD-2660
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 60000 Units per Month
    Delivery Time : 5- 8 work days
    • Product Details
    • Company Profile

    DOW Ultrafiltration Membrane Modules SFP-2660 / SFD-2660 PVDF 0.03 µm 1.3 – 4.0 m3/hr

    DOW Ultrafiltration Membrane Modules SFP-2660 / SFD-2660 PVDF 0.03 µm 1.3 – 4.0 m3/hr

    The DOW™ ultrafiltration (UF) modules are made from high strength, hollow fiber membranes that have excellent features and benefits:

    1. 1‌.Hydrophilic PVDF fiber‌: This fiber is easy to clean and wet, which helps to maintain stable performance over the long term.
    2. 2‌.External pressure structure‌: It can tolerate higher influent solid content, thereby reducing the pretreatment process.
    3. 3‌.U-PVC shell‌: No expensive pressure vessels are required, reducing costs.
    4. 4‌.Suitable for large-capacity systems‌: Suitable for systems with a capacity of more than 50m3/hr (220gpm).
    5. 5‌.Large effective membrane area‌: Larger diameter and packing density enable more economical membrane system design.
    6. 6‌.Wide application areas‌: Widely used in water treatment fields such as surface water, seawater, industrial wastewater and secondary biochemical effluent.
    7. 7‌.0.03 µm nominal membrane pore size‌: It can remove bacteria, viruses, particulate matter and colloids, and protect subsequent process equipment such as reverse osmosis systems.
    8. 8‌.High strength and strong chemical resistance‌: Ensure a longer service life of the membrane assembly.

    Product Specifications

    Membrane area

    Module volume

    Weight
    (empty/ water filled)
    Model Type Part # m2 ft2 Liters Gallons Kg lbs
    SFP-2660 Pretreatment 280931 33 355 16 4.2 25/41 55/90
    SFD-2660 NSF/ANSI 61
    Drinking water
    324166 33 355 16 4.2 25/41 55/90

    Figure 1: SFP and SFD 2660 (6-inch diameter)


    Figure 2


    Properties Length Diameter Width
    Units L L1 L2 L3 D W1 W2
    SI (mm) 1860 1500 1610 1710 165 125 250

    Operating Parameters

    SI units US units
    Filtrate Flux @ 25ºC 40-120 l/m2/ hr 24-70 gfd
    Flow range 1.3 – 4.0 m3/hr 5.9 – 17.3 gpm
    Temperature 1-40ºC 34-104ºF
    Max. inlet module pressure (@ 20ºC) 6.25 bar 93.75 psi
    Max. operating TMP 2.1 bar 30 psi
    Max operating air scour flow 12 nm3/hr 7.1 scfm
    Max backwash pressure 2.5 bar 36 psi
    Operating pH 2- 11
    NaOCl (max.) 2,000 mg/L
    TSS (max.) 100 mg/L
    Turbidity (max.) 300 ntu
    Particle size (max.) 300 µ
    Flow configuration Outside in, dead end flow
    Expected filtrate turbidity ≤0.1 NTU
    Expected filtrate SDI ≤2.5

    Proper start-up of a UF system is essential to prepare the membranes for operating service and to prevent membrane damage. Following the proper start-up sequence also helps ensure that system operating parameters conform to design specifications so that system water quality and productivity goals can be achieved. Before initiating system start-up procedures, membrane pretreatment, installation of the membrane modules, instrument calibration and other system checks should be completed.

    Operation guidelines Avoid any abrupt pressure variations during start-up, shutdown, cleaning or other sequences to prevent possible membrane damage. Flush the UF system to remove shipping solution prior to start-up. Remove residual air from the system prior to start up. Manually start the equipment. Target a permeate flow of 60% of design during initial operations. Depending on the application, permeate obtained from initial operations should be discarded. Please refer to the product technical manual.
    General information

    If operating limits and guidelines given in this bulletin are not strictly followed, the limited warranty (Form No. 795-00027) will be null and void.

    To prevent biological growth during system shutdowns, it is recommended that preservative solution be injected into the membrane modules.

    Regulatory note NSF/ANSI 61 certified drinking water modules require specific conditioning procedures prior to producing potable water. Please refer to the product technical manual flushing section for specific procedures. Drinking water modules may be subjected to additional regulatory restrictions in some countries. Please check local regulatory guidelines and application
    status before use and sale.

    Product Details:

    Place of Origin: China
    Brand Name: DOW(Acquired by DuPont)
    Certification: CE
    Model Number: SFD-2660

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: Negotiable
    Packaging Details: standard export packing
    Delivery Time: 5- 8 work days
    Supply Ability: 60000 Unit/Units per Month



    For application cases, please click:https://www.fgwater.com/Industries/

    For detailed parameters, please visit:

    1717640353442809.png image.png
    SFP-2660 SFD-2660

    About Us

    FG Water Technologies (www.fgwater.com) is now an organic part of Wuxi Fenigal Science and Technology Co. Ltd., which is a high-tech entity integrating water treatment quipment design, manufacturing, trading and shipment served for main industrial sectors.


    HAFE-FG Water Technologies has focused on the research of water treatment technology, equipment development and manufacturing, testing and international shipment etc. We work with many leading large-scale or small-medium original equipment manufacturers in China High-tech Development Zones, and engaged ourselves in R&D, manufacturing, and quality testing.

    Our main products include a variety of water purification and different treatment equipment, such as seawater reverse osmosis (SWRO) system, brackish water rever osmosis (BWRO), ultrafiltration (UF)system, Electrodeionization/EDI equipment, media pressure filters and ion exchanger softeners. So far, our company has become a major water treatment equipment supplier for food and beverage industry, pharmaceutical industry, chemical industry, electric power industry, urban water supply industry, municipal and industrial wastewater treatment and more industries, as well as being an exporter to more than 20 countries and regions in Asia, Europe, the Americas, Africa, etc.

    OUR CLIENTS

    PRODUCTION SYSTEM

    Our production system consist of a list of industry-specialized partnership factories accross China. Some of them singularly cover an area of over 10,000 square meters, including 5,000 square meters of workshop and warehouse and 1,500 square meters of office buildings. All of our technical staff has more than 10 years of experience in the design of water treatment systems, so we are able to provide the perfect solution for all kinds of water purification and sewage treatment applications.

    Since the establishment, the Company has always regarded quality as the life of our business. We choose the best components only for the production of various water treatment systems. Our systems are easy to use and maintain, and they stays highly reliable even under toughest conditions.
