Product Description:
The ASCO series 551, 552, 553 pilot/air operated spool valves are
designed with an innovative feature - connectable exhaust port.
This unique attribute provides enhanced environmental protection,
making it an excellent choice for use in hazardous areas.
Specifically, the spool valves are highly recommended for use in
sensitive areas such as clean rooms, and for applications in the
pharmaceutical and food processing industries.
The spool valves are distinct for their ability to operate through
both pilot and air, providing versatility and flexibility in use.
They have been engineered to meet all relevant EC Directives,
guaranteeing the safety and reliability of the valves.
For industries where safety is of utmost concern, the ASCO series
551, 552, 553 pilot/air operated spool valves exceed expectations.
The connectable exhaust port enhances protection against hazardous
areas, ensuring a safer work environment for personnel. These
state-of-the-art spool valves are designed to be used in a variety
of industries, offering superior performance and reliability in
even the most demanding applications.
| Weight | 0.8 kg |
| Media | Air, Gas |
| Manufacturer | Joucomatic |
| Body Material | Aluminium |
| Function | 3/2 NC |
| Port Connection | G1/2 |
| Flow Coefficient KV (l/min) | 41.5 |
| Flow Coefficient KV (m3/h) | 2.49 |
| Orifice Size | 13 mm |
| Operator Return | Spring |
| Voltage | 48V AC |
| Working Pressure Min | 2 Bar |
| Working Pressure Max | 10 Bar |
| SCG551A001MS | SCG531C002MS | EF551H401MO |
| SCG551A002MS | SCG531C017MS | EF551H402MO |
| EFG551A001MS | SCG531C018MS | SCB320B174 |
| EFG551A002MS | EFG531B017MS | EF8320G174 |
| SCG551A017MS | EF551B401MO | EF8210G003 |
| SCG551A018MS | EF551B402MO | EF8210G089 |
| SCG553A001MS | EF8551B401MO | NF8327B102MO |
| SCG553A002MS | NF8551B401MO | WSNF8327B102MO |
| SCG553A017MS | NF8551B402MO | 8262G138 |
| SCG553A018MS | EF551G401MO | 8551A421 |
| SCG531C001MS | EF551G402MO | VCEFCM8551B401MO |
Features:
The monostable spool valves are designed in accordance with the IEC
61508 Standard (2010 route2H version). These valves are certified
by TÜV (551 series) and EXIDA (551-553 series) with integrity
levels that include SIL 2 for HFT = 0 and SIL 3 for HFT = 1.
The valve boasts threaded port connections and a "NAMUR" style
interface. Additionally, these spool valves can be adapted for 3/2
NC or 5/2 functions for controlling double-acting and single-acting
actuators.
All the exhaust ports of the spool valve are connectable, providing
better environmental protection. Particularly recommended for
sensitive areas, such as clean rooms, and applications in the
pharmaceutical and food processing sectors. These valves offer
environmental protection against the ingress of liquids, dusts or
other foreign matter (environmentally-protected construction).
The valves feature an epoxy moulded coil which is ideal for general
service applications. Moreover, the solenoid valves meet all
relevant EU Directives.
Applications:
ASCO Solenoid Valve is a high-quality and reliable product used for
controlling the flow of air, inert gas, and filtered fluids. With
its model number SCG551A001MS and place of origin in China, it is
certified with CE, ensuring its quality and safety. The minimum
order quantity for this product is 1, and the price is negotiable.
It is packed in cartons or as required by clients, with delivery
time ranging from 1 to 7 work days after payment. Payment terms
include T/T, Western Union, and Paypal, with a supply ability of
5000PCs per month.
The ASCO Solenoid Valve is made with seal materials of NBR
(nitrile) and PUR (polyurethane), ensuring its durability and
longevity. It has a differential pressure of 2 - 10,4 Bar, making
it suitable for a wide range of applications. Its core tube is made
of brass, adding to its strength and durability.
The Solenoid Spool Valve has a flow of 1/4 = 700 L/min (ANR) 1/2 =
3000 L/min (5/2, 5/3), making it ideal for high-flow applications.
Its compact design allows for easy installation and operation,
making it suitable for use in various industries and applications.
The ASCO Solenoid Valve is commonly used in industrial automation,
pneumatic systems, and other applications where the control of
fluid flow is essential. It is suitable for use in industries such
as automotive, food and beverage, pharmaceuticals, and many more.
Whether you need to control the flow of air, inert gas, or filtered
fluids, the ASCO Solenoid Valve is a reliable and high-quality
product that can meet your needs. With its durability, strength,
and ease of use, it is an ideal choice for many applications.
Support and Services:
ASCO offers technical support and services for its Solenoid Valve
product line, including:
- Expert technical assistance from ASCO engineers
- Detailed product documentation and specifications
- Customized training programs for customers and distributors
- Field service support for installation, maintenance, and
troubleshooting
- Repair and replacement services for ASCO products
Packing and Shipping:
Product Packaging:
- The ASCO Solenoid Valve is packaged in a sturdy cardboard box to
ensure safe transport.
- The valve is also surrounded by protective foam to prevent any
damage during shipping.
- The packaging also includes an instruction manual and any necessary
mounting hardware.
Shipping:
- The ASCO Solenoid Valve is shipped via a reputable carrier service.
- The shipping cost is calculated based on the delivery location and
the weight of the package.
- To ensure timely delivery, customers will receive a tracking number
once the package has been shipped.
- Please note that additional shipping charges may apply for
expedited or international shipping.
