Product Description:
This hydraulic hose is available in standard lengths of 50m, 100m,
or can be customized to suit your needs. It is made with four or
six layers of spiraled high-tensile steel wire reinforcement,
making it extremely durable and capable of handling pressures
ranging from 35MPa to 85MPa.
The four or six high tensile steel wire spiral reinforcement
hydraulic hose is made of high-quality materials that ensure its
longevity and reliability. It is designed to handle high-pressure
applications and is ideal for use in a variety of industries,
including construction, mining, agriculture, and more.
The wire reinforced hydraulic hose is made with a carbon steel wire
reinforced hose that is designed to withstand even the harshest of
environments. It is resistant to abrasion, corrosion, and other
forms of damage, ensuring that it can handle the toughest jobs with
ease.
Overall, the Steel Wire Spiral Hydraulic Hose is a top-of-the-line
hydraulic hose that is perfect for those who need a high-pressure
hydraulic hose that is both durable and reliable. With its four or
six high tensile steel wire spiral reinforcement and carbon steel
wire reinforced hose, this hydraulic hose is sure to last for years
to come, no matter what your application may be.
Features:
- Product Name: Steel Wire Spiral Hydraulic Hose
- Standard: ISO18752-DC Standard
- Working Pressure: 35MPa - 85MPa
- Standard Length: 50m, 100m, Or Customized
- Hose Inside Diameter: 6.3mm - 51.0mm
- Temperature Range: -40°C To +121°C
- Features:
- Carbon steel wire reinforced hose
- Wire spiral pressure pipe
- Steel wire braided high pressure hose
Technical Parameters:
| Standard Length | 50m, 100m, Or Customized |
| Reinforcement | Four-layer Steel Wire Winding Layer |
| Hose Type | Spiral |
| Material | Steel Wire |
| Features | Small Volume Expansion Under Pressure |
| Temperature Range | -40°C To +121°C |
| Hose Inside Diameter | 6.3mm - 51.0mm |
| High Pressure | Exceed The SAE Standard By 30% |
| Working Pressure | 35MPa - 85MPa |
| Standard | ISO18752-DC Standard |
This is a wire spiral pressure pipe with four or six high tensile
steel wire spiral reinforcement hydraulic hose. It is also known as
steel wire braided high pressure hose.
Applications:
The Steel Wire Spiral Hydraulic Hose is a wire reinforced hydraulic
hose that is designed to handle high-pressure applications with
ease. The wire spiral design allows for maximum flexibility, making
it ideal for use in tight spaces and confined areas. With a minimum
order quantity of 100 m and a price range of 1-10 USD, this
hydraulic hose is an affordable solution for all your hydraulic
needs.
Whether you're working in construction, mining, agriculture, or any
other industry that requires high-pressure hydraulic systems, the
Steel Wire Spiral Hydraulic Hose is the perfect choice. With a
temperature range of -40°C to +121°C, this hydraulic hose can
handle extreme temperatures, making it ideal for use in harsh
environments.
With a standard length of 50m, 100m, or customized, the Steel Wire
Spiral Hydraulic Hose is suitable for a wide range of applications.
Its NBR Tube inner tube ensures that it is resistant to oil and
other hydraulic fluids, making it ideal for use with hydraulic
systems. The hose is built to the ISO18752-DC Standard, ensuring
that it meets the highest quality standards.
With a supply ability of 2000000 per month and a delivery time of
one month, the Steel Wire Spiral Hydraulic Hose is readily
available for all your hydraulic needs. It is packaged in cartons
to ensure that it arrives in perfect condition. Payment terms are
T/T, making it easy to purchase the hose.
In summary, the LETONE Steel Wire Spiral Hydraulic Hose is a wire
reinforced hydraulic hose that is designed to handle high-pressure
applications with ease. With a temperature range of -40°C to
+121°C, this hydraulic hose can handle extreme temperatures, making
it ideal for use in harsh environments. With a supply ability of
2000000 per month and a delivery time of one month, this hydraulic
hose is readily available for all your hydraulic needs.
Customization:
The inner tube of our wire spiral pressure pipe is made of NBR
tube, making it resistant to oil and other fluids. Our hoses have a
burst pressure range of 140MPa - 340MPa and can be customized in
standard lengths of 50m, 100m, or to meet your specific length
requirements. Our high-pressure steel wire braided hose exceeds the
SAE standard by 30%, making it a reliable choice for your hydraulic
system needs.
Support and Services:
Packing and Shipping:
Product Packaging:
- Each Steel Wire Spiral Hydraulic Hose is wrapped in plastic to
protect it from dirt and damage.
- The hoses are then bundled together and placed in a sturdy
cardboard box with packing material to prevent movement during
shipping.
Shipping:
- All orders are shipped via ground transportation.
- Orders are typically processed within 1-2 business days and shipped
within 3-5 business days.
- Shipping times may vary depending on the destination and shipping
carrier.
- Customers will receive a tracking number once their order has been
shipped.
- Please make sure to provide a valid shipping address to avoid any
delays or issues with delivery.
FAQ:
Q1: What is the brand name of the steel wire spiral hydraulic hose?
A1: The brand name of the steel wire spiral hydraulic hose is
LETONE.
Q2: Where is the steel wire spiral hydraulic hose manufactured?
A2: The steel wire spiral hydraulic hose is manufactured in China.
Q3: What is the minimum order quantity for the steel wire spiral
hydraulic hose?
A3: The minimum order quantity for the steel wire spiral hydraulic
hose is 100 meters.
Q4: What is the price range for the steel wire spiral hydraulic
hose?
A4: The price range for the steel wire spiral hydraulic hose is
between 1-10 USD.
Q5: What are the packaging details, delivery time, payment terms,
and supply ability for the steel wire spiral hydraulic hose?
A5: The packaging details for the steel wire spiral hydraulic hose
is carton. The delivery time is one month. The payment terms are
T/T. The supply ability is 2000000 per month.
