5mm 1080p 60fps Otoscope Ear Camera Endoscope Endoscopy Camera
Module
Product Description:
2MP 5mm OV2740 Micro USB Endoscope Module 140°FOV 80mm DOV. This
endoscope has a very small diameter of 5mm, equipped with a 1/6"
OV2740 sensor, HD 1080P 2MP, 1920*1080 resolution, can output
high-quality images, and is waterproof and oil-proof, reaching IP67
level.
Features:
- OV2740 Sensor
- 1/6 inch
- IP67 waterproof
- 140DFOV
- suggested DOF is 8-80mm
- MIPI Cable 1/2/3 meters
- Designed for medical
- 5mm dia
- High-quality image
- UVC compliant, Plug & Play
- Support USB2.0 OTG
Technical Parameters:
| Product Name | Endoscope Camera Module |
| Sensor | OV2740 |
| Connector | Micro USB-5P |
| DSP | USB2.0 UVC |
| Format | YUV&MJPG |
| Resolution | 1080P Max 60fps |
| Focusing Range | 8-80mm |
| Focal Length | 1.29mm |
| F Number | 5.0 |
| FOV(D) | 140° |
Customized Service:
Customized Process:
1. You can provide drawings or samples, as well as request
documentation and developed by
our engineering staff.
2. Communication or Meeting
3. We will communicate with you in detail to determine somewhat
product you need and try to set the most suitable product for you
according to your needs.
4. Sample Development
5. Determine the details of the development sample and the delivery time. Communicate at any time
to ensure smooth progress.
6. Sample Testing
7. Test and age on your application, feedback test results, no need
to modify, mass production.
Why Choose us:
Applications:
It is widely used in medical areas, like colonoscopy, laparoscopy,
duodenscope, tooth cavity endoscope, laryngoscope, colonoscope,
gastroscope, 3D laparoscopy.
