BDD91 Series Industrial Explosion Proof Pendant Lighting With 3800-56500lm Luminous

    Buy cheap BDD91 Series Industrial Explosion Proof Pendant Lighting With 3800-56500lm Luminous from wholesalers

    Buy cheap BDD91 Series Industrial Explosion Proof Pendant Lighting With 3800-56500lm Luminous from wholesalers
    • Buy cheap BDD91 Series Industrial Explosion Proof Pendant Lighting With 3800-56500lm Luminous from wholesalers

    BDD91 Series Industrial Explosion Proof Pendant Lighting With 3800-56500lm Luminous

    Ask Lasest Price
    Brand Name : Warom
    Model Number : BDD91
    Certification : IECEx; ATEX; CU-TR
    Payment Terms : T/T
    • Product Details
    • Company Profile

    BDD91 Series Industrial Explosion Proof Pendant Lighting With 3800-56500lm Luminous

    Product Introduction




    Specification
    Global (IECEx)IECEx CQM 12.0016X
    Gas and dust

    Ex d IIC T□1)Gb

    Ex t IIIC T□1)Db IP66

    Europe (ATEX)DNV 11 ATEX 05977X
    Gas and dustII 2 G Ex d IIC T□1)Gb

    II 2 D Ex tb IIIC T□1)Db IP66
    CertificatesIECEx; ATEX;CU-TR
    Conformity to standards

    EN60079-0,EN60079-1,EN60079-31

    IEC60079-0,IEC60079-1,IEC60079-31

    Degree of protectionIP66
    Ambient temperature-60℃~+55℃


    Data
    Material

    Copper-free Aluminium Alloy,powder coated surface,yellow (RAL1021),

    Toughened glass,stands 4J impact

    Weight11.2~16.7kg
    Dimensionsdifferent power has different dimension
    Lamp specificationHIE HSE HME
    Lamp power (W)70~400W
    Rated voltage220~240V AC 50/60Hz
    Rated luminous flux3800~56500lm
    Terminal3 x 1.5~4m (L+N+PE)
    Cable entries2 x M25x1.5 for bracket type, 1 x M25x1.5 for pole type.
    Cable gland(optional)DQM-II(Ex d)or DQM-III(Ex d) is recommended.


    Download

    BDD91 Series Explosion-proof Light Fittings

    (Download here:icon_pdf.gifBDD91 Series Explosion-proof Light Fittings.pdf)


    Global (IECEx): IECEx CQM 12.0016X

    (Download here:icon_pdf.gifIECEx CQM 12.0016X.pdf )
