    40 Foot Container 2 Axles Skeletal Trailers For Sale

    Ask Lasest Price
    Brand Name : GET/CIMC
    Model Number : 9302TJZ
    Certification : ISO 9001/TS16949
    Payment Terms : T/T, L/C
    Supply Ability : 200 units per month
    Delivery Time : 30 working days
    • Product Details
    • Company Profile

    40 Foot Container 2 Axles Skeletal Trailers For Sale

    40 Foot Container Skeleton Semi Trailer 2 Axles9302TJZ
    Skeleton Semi Trailer
    overall outside dimension(mm)
    Length12391
    Width2480
    Height (unload)1565
    Outside dimension of Drop Side body(mm)Length
    Width
    Height
    Tanker capacity(L)
    Skeleton Semi Trailer GVW(kg)34990
    Skeleton Semi Trailer vehicle total weight(kg)4510
    Skeleton Semi Trailer rated payload(kg)30480
    Skeleton Semi Trailer Wheel base(mm)7900+1300
    Trailer Tread(mm)Tread at front
    Tread at rear1830/1830
    Front/Rear Overhang(mm)/2041
    Approach/Departure angle(°)/15
    Rated payload of Vehicle saddle16990
    Trailer AxleBPW 12T*2
    Trailers Axle Capacity kgs9000/9000
    Tires11R22.5*8
    Trailer MaterialCarbon Steel
    Transport Material :1*20'+2*20+1*40'
    ISO Container Twist Locks4,8,12
    Tanker Insulated Covernile
    Suspension SystemLeaf Spring
    Leaf Spring Plate/7/7
    Remark:
    Stright back, installed a 40' or 20 'container . With Wabco Brake
    Steel Structure:
    Material:High strength low alloy steel with 350 MPa yield strength is used for welded I-beam and 235 MPa in other fabricated parts.
    Main Beams: 500m deep x 146mm wide x 8mm web welded I-section main beams,Top Flange 14m thick, Bottom Flange 16m thick.
    OEM Parts Configuration:
    King Pin: 3.5” /2” exchangeable king pin, Supplier: JOST.
    Container locks: 12 Sets or 8 sets.
    Landing Gear: 2 speed road side winding with sand shoe,Type: JOST C200T.
    Suspension:Mechanical suspension . options: Bogie Suspension, Air Spring Suspension
    Axles: square axle with 12 tons capacity. Supplier & type: BPW/ FUWA/SAF/L1. Made in China..
    Rims: 10 Holes ISO. Made in China. Option By the Factory..
    Tires: 11R22.5 OPTIONS: 12R22.5, 315/80R22.5,385/65R22.5 , Triangle Brand , Made in China. Option By the Factory..
    Brake System: Dual air brake system, Wabco relay emergency valve, OPTIONS: ABS. Option By the Factory.
    Brake Chamber: 30 type on front axle.30/30 type on other axles,
    Electrical System: Complete 24V installation with modular wiring harness. 7 pole plug placed at front in accordance to ISO, norms NO.1185.
    Others:
    Spare Tire Carrier: Equipped two sets per chassis without spare tire.
    Side Guard: Steel.
    Tool Box: Equipped one set.
    Painting: Color by customer’s requirement.
    Marking: By customer’s requirement.
    Options: Oil Tanker: 300L carbon steel.

    Full 3D design and Force Analysis

    Based on full understanding and analysis about transportation environment of various regions, refer to the millions of trailers’ producing experience and customer’s private condition, we design all the trailers privately to different customers.



    Best Steel chassis


    Material choose the High strength low alloy steel with 350 mpa yield strength is used for welded I-beam and 235 mpa in other fabricated parts.

    Brake Stability System


    The stability system with Dual air brake system, WABCO Valve , ABS* ,EBS* of GET Trailers acts as real-time monitoring of driving conditions of the vehicle and intervenes automatically in situations where vehicle stability enters a critical area. Its brakes specific wheels in order to help the vehicle returning to safe driving conditions, preventing rollover or out of control.

    Lift-up Axle System
*

    Lift-up Axle System can increase driving distance and reduce costs of tires significantly. Test results indicate that the total distance of tires mounted on this system can be up to 750000 km, twice or more than traditional system.

    Air Suspension
*

    Comparing to traditional leaf spring suspension, air suspension can adjust the extent of soft or firm and the height of the vehicle, provide enhanced performance of shock-absorbing and driving safety.

    Self-Steering Axles*


    Self-Steer Axle Suspension can let you much easier to turn around of a huge semi-trailer,Can let huge truck trailers works easily in the narrow space.can reduce costs of tires significantly.
