    MVR Sugar Evaporation and Syrup Concentration Solution

    Ask Lasest Price
    Brand Name : HANPU
    Model Number :
    Certification : CE,ISO9001
    Price : 100,000USD~1,000,000USD/SET
    Payment Terms : T/T,L/C,D/A,D/P,Western Union,Western Union
    Supply Ability : 1 set/ 3 months
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    MVR Sugar Evaporation and Syrup Concentration Solution

    MVR Evaporator Solution for Sugar Evaporation & Syrup Concentration

    Cane & beet sugar mills — concentrate thin juice to 60–70°Bx syrup with low energy, low color (ICUMSA), and stable crystallization.

    Hanpu delivers EPC turnkey MVR evaporator systems for sugar evaporation and syrup concentration. Our designs integrate falling-film or forced-circulation effects to protect heat-sensitive juices, curb color formation, and cut steam demand. Whether you process cane sugar or beet sugar, we help you convert thin juice into thick juice / syrup for the boiling house / pan station, improving pan capacity and crystallization stability.

    MVR sugar evaporation process diagram from thin juice to thick juice syrup

    Common challenges in sugar evaporation

    High steam consumption, sucrose inversion and caramelization at high temperature, scaling/fouling (e.g., CaCO₃, silica), rising viscosity at higher Brix, and off-spec condensate (odor/COD) that limits reuse. MVR solves these via low-temperature evaporation, optimized ΔT, and condensate polishing.

    Why Hanpu MVR for sugar mills

    custom engineered MVR sugar evaporator

    Process-specific design (cane/beet)

    low energy sugar evaporation MVR

    Low specific energy (electric-driven)

    low color syrup high Brix

    Low color (ICUMSA) at target Brix

    scaling control and CIP for sugar juice

    Anti-scaling design & CIP

    What you’ll get with us

    • A complete process package with heat & material balance and CAPEX/OPEX analysis
    • Target 60–70°Bx thick juice with temperature control for product quality
    • Falling-film / forced-circulation / hybrid selection based on viscosity & scaling risk
    • Condensate stripping/polishing for reuse in process water/boiler makeup
    • Compact skids, PLC/SCADA automation, CE/ASME compliance, retrofit-ready with existing MEE

    Skid mounted MVR sugar evaporation and syrup concentration system

    Delivery workflow

    Feed & targets → Lab/pilot (optional) → Process design & heat balance → Detailed engineering & fabrication → Installation & commissioning → Performance test & training → Maintenance & spares strategy

    Application scope

    Sugar evaporation applications cane beet thin juice thick juice pan station

    Cane thin juice evaporation · Beet thin juice to thick juice (syrup) · Syrup concentration for pan station · Condensate reuse and water-saving · Retrofit of multi-effect lines.

    Frequently Asked Questions

    Have questions about MVR sugar evaporation? Here are common FAQs. If you don’t see yours, contact us.

    Q1: MVR vs. steam-driven multi-effect—how to choose in a sugar mill?

    MVR reuses vapor via mechanical compression, ideal where electricity is competitive or steam is limited. Multi-effect uses live steam cascaded across effects. We compare your energy prices, evaporation duty, Brix and temperature limits to select or combine both.

    Q2: Can MVR reach 60–70°Bx without excessive color formation?

    Yes. Low-temperature operation and controlled ΔT help minimize sucrose inversion and caramelization, achieving low ICUMSA color at target Brix.

    Q3: Which evaporator body should I choose—falling-film or forced-circulation?

    Falling-film suits clean, heat-sensitive juice with lower viscosity; forced-circulation handles higher viscosity and scaling risk. We also offer hybrid trains to balance energy and operability.

    Q4: What about condensate quality and reuse?

    We add condensate stripping/polishing to meet reuse specs (odor/COD), enabling use as process water or boiler/cooling makeup and improving mill water balance.

    Q5: Can your MVR retrofit my existing multi-effect line?

    Yes. MVR can debottleneck existing effects or operate as a stand-alone concentrator feeding the pan station. We integrate controls, hydraulics, and CIP with your boiling house.

    Related keywords

    MVR sugar evaporation, syrup concentration, thin juice to thick juice, cane sugar, beet sugar, falling-film evaporator, forced-circulation evaporator, ICUMSA color, Brix, pan station, crystallization, condensate reuse, multi-effect retrofit.
