Structural Parameter www.jizankj.net |
Dimensions | 170mm(L) X 79mm(W) X 17.6mm(D) |
Weight | <350g |
Display Screen | 5.5-inch high definition full display(18:9),IPS LTPS 1440*720 |
Expand Port | 2 Nano-SIM Card, Micro SD (TF) Card |
Interfaces | USB3.0 Device,Type-C,OTG,extended thimble |
Input Mode | Standard Handwriting, touch input or virtual keyboard input |
Battery Capacity | Rechargeable Li-polymer Battery 3.8V 4600mAh |
Speaker | Support |
Key | 1 power key,3 scan keys,2 volume keys,1 PTT key,1 menu key,1 return
key |
Performance Parameter |
OS | Android 9.0 |
CPU | Qualcomm 2.0GHz Octa-core |
RAM+ROM | 2GB +16GB, 4GB +64GB (Optional) |
Expansion | Micro SD/TF port (Max up to 128G) |
Data Communication |
WI-FI | Support 802.11 a/b/g/n/ac/d/e/h/i/k/r/v,2.4G/5G dual-band.IPV4.IPV6 |
FDD/TDD-LTE 4G | 2G:GSM(850/900/1800/1900Mhz) 3G:WCDMA(850/900/1900/2100Mhz) CDMA EVDO:BCO 4G: (B1/B3/B5/B7/B8/B20/B38/B39/B40/B41) |
WCDMA 3G |
GSM 2G |
BT | BT4.2/4.1+HS/4.0/3.0+HS/2.1+EDR |
Standard Modules |
Camera | 16MP autofocus rear camera with flash, (optional) 8MP front camera |
GNSS | GPS/AGPS,GLONASS,BeiDou,Galileo,internal antenna |
Operating Environment |
Operating | -20°C to 50°C |
Storage Temperature | -40°C to 70°C |
Environment Humidity | 5%RH-95%RH(no condensation) |
Drop Specifications | 6 sides can bear impact from 1.5m drop to cement floor in the range
of operating temperature |
Roll Specifications | 1000 times/0.5m, roll on 6 sides contact area |
Sealed Environment | IP67 |
Barcode Scanning (OPTIONAL) |
2D SCANNER | Zebra:SE4710;Honeywell:N3603/N6603 |
1D Symbologies | UPC/EAN,Code128,Code39,Code93,Code11,Interleaved 2 of 5,Discrete 2
of 5,Codabar,MSI,RSS,etc. |
2D Symbologies | PDF417,MicroPDF417,Composite, RSS,TLC-39, Datamatrix, QR code,
Micro QR code,Aztec, MaxiCode; Postal Codes: US PostNet,US Planet,
UK Postal, Australian Postal, JapanPostal Dutch Postal (KIX),etc. |
NFC Reader (Optional) |
Frequency | 13.56MHz |
Protocol | ISO14443A/B,ISO15693,NFC-IP1,NFC-IP2,etc. |
Chips | M1 card(S50,S70),CPU card,NFC tags,etc. |
Range | 2-5cm |
