    IFM efector UIT501 Ultrasonic diffuse reflection sensor;M18 dia;range 250...3500;NO/NC; DC;PNP;M12

    Ask Lasest Price
    Brand Name : IFM
    Model Number : UIT501
    Certification : CE
    Price : USD$290
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500pc
    Delivery Time : 6-8weeks
    • Product Details
    • Company Profile

    IFM efector UIT501 Ultrasonic diffuse reflection sensor;M18 dia;range 250...3500;NO/NC; DC;PNP;M12

    Product characteristics
    Electrical designPNP
    Output functionnormally open / closed; (configurable)
    Sensing range [mm]250...3500; (Target: 200 x 200 mm)
    Communication interfaceIO-Link
    HousingThreaded type
    Dimensions [mm]M30 x 1.5 / L = 103
    Electrical data
    Operating voltage [V]10...30 DC
    Current consumption [mA]< 30
    Protection classIII
    Reverse polarity protectionyes
    Power-on delay time [s]< 0.3
    Converter frequency [kHz]112
    Inputs / outputs
    Number of inputs and outputsNumber of digital outputs: 1; Number of analog outputs: 1
    Outputs
    Total number of outputs2
    Output signalswitching signal; analog signal; IO-Link
    Electrical designPNP
    Number of digital outputs1
    Output functionnormally open / closed; (configurable)
    Max. voltage drop switching output DC [V]2.2
    Permanent current rating of switching output DC [mA]100
    Switching frequency DC [Hz]1
    Number of analog outputs1
    Analog current output [mA]4...20
    Max. load [Ω]500
    Short-circuit protectionyes
    Overload protectionyes
    Monitoring range
    Sensing range [mm]250...3500; (Target: 200 x 200 mm)
    Blind zone [mm]250
    Angle of aperture cylindrical [°]12; (±2)
    Max. deviation from the 90° angle sensor/object [°]± 4
    Accuracy / deviations
    Temperature compensationyes
    Hysteresis [%]< 3
    Switch-point drift [%]-5...5
    Linearity error of analog output [%]<3
    Repeatability1 %
    Resolution [mm]3
    Notes on the accuracy / deviationThe indicated values are reached after a warm-up time of min. 20 minutes
    Reaction times
    Response time [ms]< 600; (analog output)
    Software / programming
    Parameter setting optionshysteresis / window; second switch point; Switch-on and switch-off delay; switch-on operations; Teach function; light-on/dark-on mode
    Interfaces
    Communication interfaceIO-Link
    Transmission typeCOM2 (38,4 kBaud)
    IO-Link revision1.1
    SDCI standardIEC 61131-9
    ProfilesSmart Sensor: Device Identification; Multi-channel, two setpoint switching sensor, type 0 Generic Profiled Sensor; Process Data Variable; Device Diagnosis; Teach Channel
    SIO modeyes
    Required master port classA
    Min. process cycle time [ms]3.2
    IO-Link process data (cyclical)
    Functionbit length
    process value16
    device status4
    binary switching information2
    IO-Link functions (acyclical)application specific tag; operating hours counter
    Supported DeviceIDs
    Type of operationDeviceID
    default1094
    Note
    For further information please see the IODD PDF file at "Downloads"
    Operating conditions
    Ambient temperature [°C]-20...70
    Storage temperature [°C]-30...80
    ProtectionIP 67
    Tests / approvals
    EMC
    EN 61000-4-2 ESD4 kV CD / 8 kV AD
    EN 61000-4-3 HF radiated3 V/m
    EN 61000-4-4 Burst2 kV
    EN 61000-4-6 HF conducted3 V
    EN 55011class A
    Vibration resistance
    EN 60068-2-6 Fc(10-55) Hz 1 mm amplitude, vibration duration 5 min., 30 min. per axis with resonance or 55 Hz
    Shock resistance
    EN 60068-2-27 Ea30 g 11 ms half-sine; 3 shocks each in every direction of the 3 coordinate axes
    MTTF [years]117
    UL approval
    Ta-20...70 °C
    voltage supplyClass 2
    File number ULE174191
    Mechanical data
    Weight [g]227
    HousingThreaded type
    Dimensions [mm]M30 x 1.5 / L = 103
    Thread designationM30 x 1.5
    Materialstainless steel (1.4404 / 316L); PA; epoxy glass ceramics
    Tightening torque [Nm]100
    Displays / operating elements
    Display
    Switching status2 x LED, yellow
    echo1 x LED, green
    Teach functionyes
    Accessories
    Items supplied
    lock nuts: 2, stainless steel
    Remarks
    Remarks
    cULus - Class 2 source required
    Pack quantity1 pcs.
    Electrical connection
    ConnectionConnector: 1 x M12; coding: A
