Max.PV Array Power 4000W Hybrid Solar Inverter with 500VDC Max Open
Circuit and 15A Input Current
4000W Hybrid Solar Inverter Product Description:
One of the standout features of this inverter is its maximum solar
charge current of 100A. This means that it can take full advantage
of available solar power and charge batteries quickly. The MPPT
voltage range is also impressive, ranging from 120V to 450V. This
allows for maximum flexibility when it comes to setting up solar
arrays.
The Solar Hybrid Inverter is capable of producing a maximum PV
array power of 3500W. This makes it suitable for use in a wide
range of applications, from small residential systems to larger
commercial setups. It can output a frequency of 50/60(HZ), making
it compatible with most standard electrical devices.
When you purchase this Solar Hybrid Inverter, you can rest assured
that you are getting a high-quality product. It comes with a 2-year
warranty, giving you peace of mind and protection against any
defects or issues that may arise.
4000W Hybrid Solar Inverter Features:
- Parallel Operation: The system allows multiple units to operate
together in parallel, combining their output power or capacity.
This enables increased overall power or capacity compared to using
a single unit.
- Single-phase/Three-phase Support: The system can be configured to
support both single-phase and three-phase operation. This
flexibility allows it to be compatible with various types of
electrical systems.
- Wireless Parallel: The units can communicate wirelessly with each
other to synchronize their operation and ensure proper parallel
operation. This eliminates the need for physical wiring connections
between the units.
- Multiple Output Priority: The system supports multiple output
priority modes. These modes include UTL, SOL , SBU and SUB. These
modes determine the preferred source of power or load distribution.
4000W Hybrid Solar Inverter Technical Parameters:
Max.AC Charge Current | 60A |
Output Voltage | 230VAC ± 5% |
MPPT voltage range | 120V-450V |
Humidity | 5% to 95% Relative Humidity (Non-condensing) |
Operating Temperature Range | -10℃~50℃ |
Warranty | 2 Years |
Inverter Type | Pure Sine Wave Solar Inverter |
Max.PV Array Open Circuit Voltage | 500VDC |
Size | 482*290*113mm |
Rated power | 3500VA/ 3500W |
Communication | USB/RS232/Dry-contact |
DC/AC Inverters | Output Type: Single phase |
4000W Hybrid Solar Inverter Applications:
The COENG 3500HHS-24 Solar Hybrid Inverter is a reliable and
efficient solution for powering homes and small businesses. Made in
China and certified by CE and IEC, this inverter can be ordered
with a minimum quantity of 1 at a price range of $254.90-$299.90
per piece. The packaging details include carton and pallet, and the
delivery time ranges from 10-30 working days. The payment terms
accepted are L/C and T/T, and the supply ability is 20,000 pieces
per month.
With an operating temperature range of -10℃~50℃, the 3500HHS-24
Solar Hybrid Inverter is suitable for use in various weather
conditions. It has a maximum solar input current of 15A and an MPPT
voltage range of 120V-450V. The inverter's max PV array open
circuit voltage is 500VDC, making it compatible with a wide range
of solar panels.
The 3500HHS-24 Solar Hybrid Inverter has a single-phase output type
with an output voltage of 220/230VAC, making it a perfect choice
for small scale applications. With a gross weight of 12.000 kg,
this compact inverter can be easily installed in homes and small
businesses.
This inverter is suitable for various application occasions and
scenarios, including powering homes, small businesses, and farms
with solar energy. Its reliable and efficient performance makes it
an ideal choice for off-grid and on-grid solar systems.
4000W Hybrid Solar Inverter Support and Services:
The Solar Hybrid Inverter is a highly efficient and reliable
product that combines the functionality of a solar inverter and a
traditional inverter. It is designed to maximize the use of solar
power, while still providing backup power from the grid or
batteries when needed.
Our product technical support team is available to assist with any
questions or issues related to the Solar Hybrid Inverter. We offer
troubleshooting assistance, software updates, and product
maintenance services to ensure optimal performance.
In addition to technical support, we also offer installation and
commissioning services to ensure that the Solar Hybrid Inverter is
properly integrated into your solar power system. Our experienced
technicians will work with you to ensure that the installation is
seamless and meets your specific needs.
Overall, our goal is to provide our customers with the highest
level of service and support for the Solar Hybrid Inverter. We
stand behind our product and are committed to ensuring that it
performs at its best for years to come.
