Product IBOX-1226 J6412 Industrial Fanless Mini PC Description:
With its sleek black design, this mini PC is not only visually
appealing but also highly functional. It is equipped with a DC 12V
input voltage, making it easy to install and operate. It also comes
with CE, CCC, FCC Class A, and ROHS certificates, ensuring that it
meets the highest quality and safety standards.
The CPU architecture of this Industrial PC Power Supply is Gemini
Lake Refresh, providing efficient and reliable computing power. It
is also fanless, making it ideal for harsh industrial environments
where dust, dirt, and other contaminants can damage traditional
fan-cooled systems. This Industrial Fanless Mini PC is built to
withstand extreme temperatures, humidity, and vibration, ensuring
long-term reliability and performance.
Whether you need a mini PC for industrial automation, medical
imaging, logistics transportation, warehouse management, or
electronic education, our Fanless Industrial Panel PC is the
perfect choice. It is highly flexible and versatile, allowing for
easy customization and integration with various industrial
applications.
So why wait? Get your hands on this powerful and reliable
Industrial Fanless Mini PC today and experience the best in
industrial computing!
Features:
- Product Name: Industrial Mini PC
- Model: IBOX-1226
- Memory: Support 1*DDR4 3200MT/s SODIMM, Max 32 GB
- BIOS: AMI UEFI BIOS
- Material: High-quality all aluminum, surface hard anodized
- Processor Core: Onboard Intel Celeron J6412 (quad core, four
threads, 2.0GHz,Max to 2.6GHz)
- Display Chip: Integrated Intel HD Graphics
- Display Port: USB 2.0, HDMI, VGA,1*HDMI, 1*DP (Support
Synchronous/asynchronous display)
- Storage: 1*M.2 slot (SATA protocol) , 1*2.5” SSD/HDD
- USB: 2* USB2.0
Technical Parameters:
| Specification |
| Module | IBOX-1226 |
| Color | Dark grey (color can be customized) |
| Material | High-quality all aluminum, surface hard anodized |
| Processor | Onboard Intel Celeron J6412 (quad core, four threads, 2.0GHz,Max to
2.6GHz) |
| Memory | Support 1*DDR4 3200MT/s SODIMM, Max 32 GB |
| BIOS | AMI UEFI BIOS |
| Display Chip | Integrated Intel HD Graphics |
| Display Port | 1*HDMI, 1*DP (Support Synchronous/asynchronous display) |
| Front I/O | 4*COM, 2* USB2.0, 1*Intel 2.5G Lan, 18 bits GPIO Phoenix, 1*Power
switch |
| Rear I/O | 2*COM (COM1 and 2, RS232/485 optional) 2*USB2.0, 2*USB3.0, 2*Intel
2.5G Lan |
| 1*HDMI, 1*DP, 1* 2Pin Phoenix, 1*Audio with Mic and Speaker |
| Expansion Slot | 1*M.2 M-key slot 2280, SATA protocol |
| 1*M.2 B-key slot 3042/3052 (for 4G/5G module) with SIM slot; |
| 1*MINI PCIE slot (for WIFI&BT) |
| 2*USB2.0 (Extensible ports, standard does not include) |
| Network | 3*Intel i226-V 2.5G Lan |
| Storage | 1*M.2 slot (SATA protocol) , 1*2.5” SSD/HDD |
| Power Supply | DC 12V in put (DC 9-36V Optional ) |
| Other functions | Auto Power-on, Timed power-on, network wake-up, PXE boot, watchdog
(level 0-255), TPM2.0 security encryption |
| Work Temp | 0℃ - +50℃ (Commercial HDD), -20℃ to -60℃ (Industrial SSD), Surface
air flow |
| Work Humidity | 5% -95% non-condensing |
| Certificates | CE, CCC, FCC Class A, RoHS |
| Size | 186 * 140 * 66 mm |
| Weight | 1.5 kg |
| Application | Industrial automation, Medical, Transportation, Warehousing,
E-education etc. |
IBOX-1226 Drawing:
| Accessories List |
| Name | Quantity | Specification |
| Power Adapter | 1 | 12V 5A |
| Power Cord | 1 | US standard, EU standard, etc. |
| Wall bracket | 2 | Standard |
| Order information |
| Configuration 1 | IBOX-1226 | Intel Celeron J6412 | Standard I/O |
Applications:
One of the main advantages of the MTHGH IBOX-1226 is its fanless design, making it a reliable and durable option for
industrial automation, medical, logistics transportation,
warehouse, electronic education, and other similar applications.
With no fan, there is less risk of dust and other contaminants
entering the system, allowing for a longer lifespan and minimal
maintenance requirements.
As a fanless industrial panel PC, the MTHGH IBOX-1226 is also an excellent option for use in harsh environments. It can
withstand extreme temperatures, humidity, and vibrations, ensuring
stable performance under challenging conditions.
The MTHGH IBOX-1226 also features various ports, including USB 2.0, HDMI, and VGA,
making it easy to connect to other devices and peripherals. It has
a net weight of 2.0kg, making it lightweight and easy to install in
various locations.
This industrial touch panel PC is also certified with CE, CCC, FCC
Class A, and ROHS, ensuring compliance with industry standards and
regulations.
Overall, the MTHGH IBOX-1226 is a reliable and robust fanless industrial panel PC that is
suitable for a range of industrial applications. Its fanless
design, quad-core processor, and various ports make it a versatile
and efficient choice for industrial automation, medical, logistics
transportation, warehouse, electronic education, and more.
