    AC12V Ground Terminal Short-term High Current Resistance Test System

    Ask Lasest Price
    Brand Name : Sinuo
    Model Number : SNQC1020
    Certification : Calibration Certificate (Cost Additional)
    Payment Terms : T/T
    Supply Ability : 10 Sets Per Month
    Delivery Time : 30 Days
    • Product Details
    • Company Profile

    AC12V Ground Terminal Short-term High Current Resistance Test System


    AC12V Ground Terminal Short-term High Current Resistance Test System


    Complied Standards & Clauses



    Conforms to IEC 62192-1:2022, etc.


    Product Overview



    It adopts independent programming software and computer-controlled operation. All standard test procedures and data judgments are controlled by the system, making it easy to operate. It provides AC30~8000A adjustable AC constant current source, which can be used for ground resistance testing, appliance switches, plugs and sockets, and switch cabinets. , busbar and other products temperature rise test. It has the characteristics of easy operation, accuracy and reliability, and is widely used in manufacturers, quality inspection and scientific research departments. It can also be used to assess the surface heating of electrical accessories when connected to a load current and whether the electrode temperature rise meets the requirements of the standard.


    Technical Parameters




    Constant test current source

    Maximum output voltage: less than AC12V

    Test frequency 50Hz/60Hz can be set

    Constant test current source: 30.0~8000A continuously adjustable

    Current display accuracy: ± (0.25% reading + 0.25% range), resolution 0.1A/1A

    Test current stability: ±(1% set value + 5A)

    Current rise time: The time for the current to reach the set current value (maximum value 8000A) from 0A at the beginning of the test does not exceed 0.5s. Current rise stabilization time: about 0.5S

    Number of output phases: single phase, one station;

    Operating modeContinuous mode, on-off mode
    Continuous mode power on time, power on and off time1~999.9 seconds/minute/hour
    Number of on-off times1~9999 times, with power-off memory function, automatic shutdown when the number reaches
    Control methodEquipped with PLC modules from well-known brands such as Siemens, Mitsubishi, and Omron, and equipped with a 7-inch or above color LCD touch control screen;
    Operation modeManual or program-controlled operation;
    Safety protectionWith overload, overvoltage and overheating protection functions;
    AccessoriesManual, power cord about 3 meters
    Power supplyThree-phase AC380V±10%, 50Hz, 150KVA
    Main configuration
    NameSpecificationBrandQuantity
    ComputerPen 4/1.8G or above CPU, 4G memory, 64G solid state drive, 15-inch LCD monitor), installed with XP Chinese operating system, OFFICE processing softwareCUSN1
    CabinetAnti-static sprayingCustomize1
    Programmable current source10V 8000ACustomize1
    Test fixtureAccording to standardCustomize1
    Program-controlled test recording softwareTest controlCustomize1
