Waterproof 38L SMT Cleaning Equipment with Constant Temperature
System
Features
1, High power transducer cleaning effect significantly, usable
macroscopic observation;
2, After cleaning objects shine light;
3, Digital LCD control boot time;
4, The stainless steel and the lid, bladder, more upscale;
5, Waterproof properties is greatly improved, more safety products
last;
6, With constant temperature system with heating.
Specification
| Model | HS-120ST |
| Ultrasonic frequency | 28/40 kHz |
| The tank material | Stainless steel SUS304 stamping slot |
| Tank capacity | 38L |
| Timer | 1~99 min adjustable |
| Heater | 0 ~80℃ adjustable |
| Power | AC 100 ~ 120 V, 60 Hz/AC 200 ~ 240 V, 50 Hz |
| Ultrasonic power | 40~600 W adjustable, 12 transducers |
| Heating power | 1500W |
| The tank size | 500 x 300 x 250 mm (L x W x H) |
| Shape dimension | 670 x 480 x 700 mm (L x W x H) |
| N.W | 30KG |
| G.W | 35KG |
| Certification | CE,RoHS |
Ultrasonic device
1, Ultrasonic installation method: bottom-mounted shock plate;
2, 72 vibrators are installed at the bottom of the tank; Ultrasonic
power: 0-3600W can be adjusted
3, ultrasonic power: 0 ~ 1800W * 2 sets (continuously adjustable),
ultrasonic frequency 28 / 40KHz
4, The ultrasonic transducer adopts the pure industrial shock head
imported from South Korea, which has large cleaning power and long
service life;
5, Adopting the latest bonding technology of Korea and imported
special adhesive to ensure better bonding performance between the
transducer and the vibrating surface. No degumming considerations,
stable performance. The transducers are all reinforced and equipped
with high frequency wires.
