Installation Method:
1. Find the strongest direction and position of the received signal
for mobiles at the top or the periphery of the building, as the
location for installing the outdoor antenna, pay attention that the
location should be paid to lightning protection.
The installation height should not be higher than the lightning
protection network of the building. If it is higher than the
lightning protection network. If it is necessary, install a
lightning rod 1 meter above the outdoor antenna and ground it well.
2. After selecting the appropriate location, fix the outdoor
antenna to the wall or bracket.
3. Select an appropriate location in the relevant indoor location
(close to the power supply and the outdoor antenna end, rain-proof,
sunshine-proof and ventilation is best location) install indoor
straight machine, and fixed to the wall or bracket.
4. Lead the outdoor antenna to the 'BTS' (outdoor) interface, and
the connection between the outdoor antenna and the amplifier is
completed.
5. After defining the indoor antenna installation position, fix the
antenna.
6. The indoor antenna connected to the amplifier, one port
connecting to the indoor antenna interface, and the other port
connecting to the repeater's 'MOBILE' (indoor) port.
