GYXTW Single-mode 2-12 Core Steel Tape Armored Fiber Optic Cable with G652D PE for LAN Communication

    Buy cheap GYXTW Single-mode 2-12 Core Steel Tape Armored Fiber Optic Cable with G652D PE for LAN Communication from wholesalers

    Buy cheap GYXTW Single-mode 2-12 Core Steel Tape Armored Fiber Optic Cable with G652D PE for LAN Communication from wholesalers
    • Buy cheap GYXTW Single-mode 2-12 Core Steel Tape Armored Fiber Optic Cable with G652D PE for LAN Communication from wholesalers
    • Buy cheap GYXTW Single-mode 2-12 Core Steel Tape Armored Fiber Optic Cable with G652D PE for LAN Communication from wholesalers

    GYXTW Single-mode 2-12 Core Steel Tape Armored Fiber Optic Cable with G652D PE for LAN Communication

    Ask Lasest Price
    Brand Name : EBOCOM
    Model Number : GYXTW
    Certification : ISO TLC
    Price : EXW ≥2000m $0.038/M ≥5000m $0.034/M
    Payment Terms : T/T
    Supply Ability : 5000KMS/day
    Delivery Time : 5-8 days
    • Product Details
    • Company Profile

    GYXTW Single-mode 2-12 Core Steel Tape Armored Fiber Optic Cable with G652D PE for LAN Communication

    GYXTW optical cable, central tube type (2~12 cores), the tube contains fiber core and grease, plus steel tape armor, and PE outer sheath prevents two reinforced parallel steel wires. Suitable for duct or overhead applications. Tubes contain optical fibers that are color-coded according to a color-coding scheme. Generally speaking, G652D single-mode fiber is more widely used.

    Application
    This cable is ideal for in long distance and inter office communication in strong current zone, as well as power transmission system. The built in suspension stranded rope provides high tensile strength, enabling the cable suited for large span installation, resulting in time and installation cost savings. The suspension wire, being an integral part of the cable, is easily available for gripping, fastening and pulling. This cable is featured of its lightness, low dispersion and high tensile strength.


    Product application
    1. Adopted to outdoor distribution
    2. Suitable for aerial, pipeline laying method
    3. Long distance and local area network communication


    Mechanical & Environmental Characteristics

    ITEMValue
    Max. Tensile Load (Short Term)2000N
    Max. Tensile Load (Long Term)1000N
    Max. Crush Load (Short Term)1000N/100mm
    Max Crush Load (Long Term)300N/100mm
    UL Fire RatedOFNR
    Operating Temperature-20°C to +60°C
    Storage Temperature-40°C to +85°C
    Sheath MaterialStandard: PE Optional: LSZH or other

    Company Profile

    Shandong Yibo Optronics Technology Co., Ltd. (Ebocom®), established in 2012, is located in the beautiful spring city
    of Jinan, covering an area of 26,600 ㎡ . It is a high-tech enterprise focusing on the research and development, production, sales and service of optical cables and communication equipment. Ebocom® is committed to the research, development and application of optical cable products and communication
    products. Our products include various types of optical cables (outdoor/indoor optical cables, ADSS, OPGW, mining
    cables, FTTH drop cables, patch cord and pigtails) as well as optical cable-related connectors, accessories and
    equipment. Widely used in telecom operators, data centers, enterprise networks and other communication
    infrastructure fields. The products strictly implement national standards and have obtained ISO9001, ISO14001, ISO45001, ISO50001, TLC certification, and National Radio and Television Administration network access certification. It also has 3 invention patents and 27 utility model patents. Ebocom® focus on R&D innovation and constantly pursue advancement in technology to meet the changing needs
    of our customers. The company actively introduces advanced foreign production equipment and inspection equipment (optical fiber coloring equipment, secondary coating equipment, OPGW unit tube production equipment, precision optical fiber detectors), and absorbs advanced domestic and foreign process technology to ensure the high quality and quality of products. reliability. In order to further ensure product quality, the company has established a strict management system and checks every step of the production process at all levels. Over more than ten years of continuous innovation and development, Ebocom® has won many honors, such as "High-tech Enterprise", "Gazelle Enterprise", "Specialized Special New specialized and sophisticated Enterprise", Shandong Province Excellent Management Innovation Enterprise", "AAA Credit Unit" , "Contract-abiding and Credit-worthy Unit", etc.
