400G QSFP112 SR4 Optical Transceiver Module

Experience high-performance data center connectivity with our 400G QSFP112 SR4 optical transceiver module. Designed for short-reach multimode fiber applications, this module supports data rates up to 425Gbps over 100m using OM4 fiber. Featuring low power consumption, hot-pluggability, and robust diagnostic monitoring, it is an ideal solution for modern data centers and high-speed networks.

Key Features

• Hot-pluggable QSFP112 form factor with digital diagnostics monitoring (DDM)
• 4 independent lanes at 106.25Gbps per lane, totaling 425Gbps
• Reach up to 100m on OM4 multimode fiber
• 850nm VCSEL laser and PIN receiver technology
• Low power consumption, max 10W
• Compliant with IEEE 802.3db, 802.3ck, and CMIS 4.0
• RoHS 6/6 compliant and Class 1 Laser product

Technology & Standards

This optical module complies with industry standards including IEEE 802.3db, IEEE 802.3ck, and the QSFP112 MSA. It uses PAM4 modulation and supports 400GAUI-4 electrical interface. The module integrates advanced digital diagnostics for real-time monitoring of temperature, voltage, TX/RX power, and bias current.

Working Principle

The transceiver converts electrical signals into optical signals using four 850nm VCSEL lasers. Each lane operates independently, transmitting data over OM4 fiber via an MPO-12 connector. On the receiver side, a PIN photodiode array converts the optical signals back to electrical data, ensuring high-speed, low-latency communication.

Applications

• Data center interconnects and spine-leaf architectures
• High-performance computing (HPC) clusters
• Cloud infrastructure and enterprise networking
• Telecommunication and ISP core networks

Specifications

Advantages

• Higher port density and lower power per bit compared to previous generations
• Fully compliant with MSA and IEEE standards for broad compatibility
• Advanced DDM for real-time network health monitoring
• Robust metal housing for improved EMI performance

Service & Support

We offer a 5-year warranty, 24/7 technical support, and global shipping. Our team provides integration assistance and custom configuration services to ensure seamless deployment.

FAQ

Q: What is the maximum distance supported?
A: This optical transceiver module supports up to 100m on OM4 multimode fiber.

Q: Is it compatible with Cisco/Juniper/Arista switches?
A: Yes, it is designed to be compatible with major brands that support QSFP112 form factor.

Q: What diagnostic data is available?
A: Temperature, voltage, TX/RX power, and bias current per channel.

Precautions

• Operate within specified temperature and humidity ranges
• Use appropriate ESD protection during handling
• Ensure host system compatibility before installation
• Avoid bending fiber cables beyond minimum bend radius
