Structure Composition of Air Suspension System

1. Air spring is the core component of the air shock absorber, similar to a hollow rubber air bag. Its main role is to change its own height and hardness by filling or discharging air, so as to achieve the adjustment of the body height and shock absorption effect.

2. Piston connected to the piston rod, moving up and down in the gas chamber, converting the mechanical energy transmitted by the wheel into the pressure energy of the gas, so as to achieve shock absorption.

3. Piston rod plays a role in connecting the piston and the body, and transmits the movement of the wheel to the piston.

4. Gas storage tank used to store high-pressure gas to provide a stable air source for air shock absorbers.

5. Control components such as solenoid valves used to control the inlet and outlet of gas and pressure regulation to achieve precise control of shock absorber hardness and body height.

Specification of Air Suspension Parts

1. The shock absorption effect is stable: the unique feature of the air shock absorber is that the natural frequency of the system does not change significantly when the load changes. This characteristic, combined with precise height control, results in better shock absorption.

2. High precision level control: The air shock absorber can adjust the internal air pressure through the mechanical level control valve for accurate height control. This feature meets the high requirements for the horizontal precision of the workbench equipment.

3. Good noise reduction effect: the air shock absorber can effectively reduce the noise transmitted through the structure. The air shock absorber itself does not produce noise and does not have the flutter problem of traditional coil springs.
