400G QSFP-DD ER4 Lite PAM4 4 LWDM Lanes MUX/DEMUX design Optical
Transceiver Module (LWDM4 SMF LC 30km with FEC DDM)
The product is a 400Gb/s quad-channel small form factor pluggable
dual density (QSFP-DD) optical module designed for optical
communication applications. The module converts 8 channels of
50Gb/s (PAM4) electrical input data into four LAN-WDM optical
signals, multiplexed into one channel for 400Gb/s optical
transmission. Conversely, on the receiver side, the module
optically demultiplexes the 400Gb/s optical input into four
channels of WDM optical signals and converts them into 8 channels
of 50Gb/s (PAM4) electrical output data. The four LAN WDM channels
have center wavelengths of 1295.56, 1300.05, 1304.58, and 1309.14
nm, which belong to the LAN WDM wavelength grid defined in
IEEE802.3ba. It contains a duplex LC connector for the optical
interface and a 76-pin connector for the electrical interface. The
400G KP4 FEC can support transmission distances of up to 30
kilometers. The electrical interface is IEEE 802.3bs compliant with
QSFP-DD MSA in the transceiver direction, and the optical interface
is IEEE 802.3bs compliant with a duplex LC connector.
Feature:
- Max Power Consumption ≤12W.
- Provide Professional Compatibility and Parameter Test Reports.
- Compliant with Hot Pluggable QSFP-DD MSA,CMIS 4.0, IEEE 802.3cn
Standard.
- Class1/1M Standard Product, Compliant with RoHS Environmental
Protection Standards (Lead-Free).
- DDM(Digital Diagnostic Monitoring) Supported.
- 30-Day Free Return, 1-Year Free Replacement, 3-Year Warranty,
Lifetime After-sales Technical Support.
Quality Assurance
Excellent quality is the foundation of Comelink's survival and
development. Our operation team are experts with many years'
experience in the optical communication industry. Our manufacturers
are first-class manufacturers in the industry. Many of them have
the qualification of OEM for first-class system equipment
manufacturers.
Specificiation
| P/N | QSFP-DD-400G-ER4L | Vendor Name | Comelink |
| Form Factor | QSFP-DD | Max Data Rate | 425Gbps |
| Wavelength | 1295.56nm, 1300.05nm, 1304.58nm, 1309.14nm | Max Distance | 30km |
| Modulation Format | PAM4 | Host Required | with FEC |
| Connector | Duplex LC | Voltage Supply | 3.3V |
| Cable Type | SMF | DDM Support | Yes |
| Transmitter Type | EML LWDM | Receiver Type | APD |
| TX Power | +0.4~+6.5dBm | Receiver Sensitivity | <-12.1dBm |
| Operation Temperature | 0 to 70°C (32 to 158°F) | Maximum Power | < 12.0W |
| Protocols | QSFP-DD MSA, IEEE 802.3bs | Application | 400G Ethernet, Data Center Interconnects, Infiniband Interconnects,
Enterprise Networking |
Application:
Comprehensive Testing Increases Reliability
Qualified through a rigorous process with advanced equipments to
ensure you get the high quality and reliable optics.
Unleash HPC Power with InfiniBand Architecture
We provides the Infiniband network solution, offering significant
advantages in terms of high-speed, low latency, scalability, and
efficiency.
Flat Top OSFP Connector Shell
The OSFP shell has a flat top and is used in adapters, such as
ConnectX-7 InfiniBand Adapter Cards.
