    OV7670 MIPI Camera Module DVP 0.3MP COMS VGA Camera Module Face Recognition

    Ask Lasest Price
    Brand Name : HAOZHOU / OEM
    Model Number : HZ-60-7670 S1.0
    Certification : CE / RoHS / FCC / ISO
    Price : 4~8USD
    Payment Terms : L/C,T/T,Western Union,MoneyGram,Paypay and others
    Supply Ability : 500000 pieces/month
    Delivery Time : 7 - 15 Work Days
    • Product Details
    • Company Profile

    OV7670 MIPI Camera Module DVP 0.3MP COMS VGA Camera Module Face Recognition

    OEM omnivision OV7670 0.3mp VGA MIPI CMOS Camera module Sensor FPC special 24PIN DVP connector Camera Module 480P

    Product description
    24 PIN Camera Module
    • OV7670 MIPI Camera is a high-performance CMOS image sensor launched by OmniVision, designed for embedded vision applications. OV7670 Camera Modules support VGA (640×480) resolution, up to 30 frames per second, and integrated image processing functions. The module is equipped with a 24-pin DVP/MIPI interface and is compatible with a variety of embedded systems and development platforms, such as Raspberry Pi. It is suitable for a variety of low-power scenarios such as QR code/barcode scanning, POS machines, mobile devices and micro camera applications.

    MIPI Mini Camera Modules

    • The OV7670 mini Camera uses a small package, compact size, and easy integration. It supports RAW RGB, YUV and compressed image output formats, and is compatible with a variety of microcontrollers and DSP processors. It is an ideal choice for low-cost image acquisition solutions. In addition, 0mniVision sensors use proprietary sensor technology to improve image quality by reducing or eliminating common lighting/electrical pollution sources, resulting in clean, fully stable color images.

    OV7670 DVP camera module Functions and Features

    1. VGA resolution: supports 640×480 pixel image output to meet the needs of basic visual applications.
    2. High frame rate: up to 30 frames/second (VGA mode) to ensure smooth dynamic image capture.
    3. Low power design: operating voltage 3.3V, suitable for battery-powered portable devices.
    4. Multiple data formats: supports RAW RGB, YUV (422/420), GRB 4:2:2 and other output formats to adapt to different processor requirements.
    5. Integrated image processing: built-in automatic exposure control (AEC), automatic white balance (AWB), automatic gain control (AGC) and other algorithms to optimize image quality.
    6. Flexible interface: supports SCCB (I²C-like) control interface and 8/10-bit parallel data output, compatible with mainstream MCUs (such as STM32, Arduino).
    7. Compact package: small size design (such as COB or CSP package) for easy integration into space-constrained devices.
    8. Low-cost solution: Affordable and suitable for consumer electronics, education and DIY project development.

    CMOS Camera Module Applications

    Smart home devices, industrial inspection, drones, robot vision, surveillance cameras, toys and interactive devices, portable medical devices, reversing images, driving recorders, environmental monitoring, etc.

    Specifications: OV7670 30W 30 FPS Camera

    Module No.
    HZ-60-7670 S1.0
    Module Size
    OEM
    Object distance
    10cm-∞
    Resolution
    ≥1800lW/PH(Center)
    Focus
    Fixed Focus
    Interface
    MIPI
    Voltage
    5v
    Temperature (Operation)
    -30°C to 70°C
    Temperature (Stable Image)
    0°C to 50°C
    Operating system request
    Windows 2000 ,Windows XP/ 7 / 8
    Package
    Anti-electrostatic tray
    Sensor Type
    TBD
    Sensor No.
    OV7670
    Sercor Type
    1/6''
    Active Array Size
    640*480
    Sensitivity
    46dB
    Pixel Size
    3.6µm x 3.6µm
    Maximum Image Transfer Rate
    640*480(VGA)@30fps@24Mhz,VGA
    SNR
    46dB
    ADC resolution
    10 bit ADC
    Dynamic Range
    52dB
    LENS
    Thread
    M6.5XP0.25
    Lens Construction
    2P
    F/NO
    2.2mm
    EFL
    3.46mm
    FOV
    79.8°
    IR Filter
    650nm
    TV Distortion
    <1.0%
    DSP Type
    GC/EC/Whiter balance
    Auto
    Output Formats
    RAW-RGB
    Certifications
    Certifications
    FCC and CE
