Automotive Anodizing Production System for Wheel Rims

Automotive Anodizing Production System for Wheel Rims

Anodizing Production System Overview:

Our automotive anodizing production system for wheel rims offers high - speed production. It can process 5000 wheel rims per day, creating 200 + finishes. The color - mixing system provides diverse color options. The anti - scratch design protects rims during processing. Meeting OEM requirements, it’s popular among automotive wheel manufacturers.

Partial parameter description of Anodizing Production System:

Tank 15,17,19, and 21:4 coloring tank

1-7-1 structure:

It is made of stainless steel plate bent and welded with SS304 material, with a thickness of 3mm, which ensures that the tank is not deformed, beautiful, non-leakage, corrosion-resistant and easy to maintain. The bottom of the tank is equipped with side drainage port.

1) Tank size: 800 x 4000 x 1600mm (L x W x H)

2) Reinforcement of the tank: 80*40*4mm square tube made of A3 material is welded

3) The thickness of the insulation layer of the tank is 50mm, and the material is 100K rock wool. The outer plate is 1mm thick and 304# stainless steel plate is covered with rivet

4) A set of stainless steel 304 serpentine steam heating tubes are configured in the tank.

5) Two exhaust hoods are arranged on both sides of the tank and connected to the exhaust main pipe.

1-7-2 piping:

1) Pure water pipe: φ3/4" PVC pipe (with PVC ball valve).

2) Drainage pipe: φ3" PVC pipe (with fittings/spherical valve).

3) Stirring: air stirring (φ3/4" PP pipe)

For a complete technical solution of Anodizing Production System, please contact me. We will customize the design based on your product technical requirements and factory layout.

Basic process flow Of Anodizing Production System :

Feed material → 1 Chemical degreasing → 2 Water washing → 3 Alkali etching → 4 Water washing → 5 Water washing → 6 Acid washing → 7 Water washing → 8 Water washing → 9 Anodizing → 10 Anodizing → 11 Anodizing → 12 Water washing → 13 Water washing → 14 Coloring → 15 Water washing → 16 Coloring → 17 Water washing → 18 Coloring → 19 Water washing → 20 Coloring → 21 Water washing → Unloading

Working conditions Of Anodizing Production System :

Our typical customers:

Installation and training Of Anodizing Production System :

1. Installation

1) The seller shall provide all details of the equipment installation to the user in order to prepare the installation site.

2) The seller shall install and debug the equipment at the user's factory site.

2. Training

During the installation, the seller provides on-site training for plant operators, including normal operation, maintenance, analysis of operational problems and emergency procedures.
