| Brand Name : | Jingtu |
| Model Number : | JT-7800 Black |
| Certification : | MSDS SGS |
| Supply Ability : | 10000 ton/month |
Composition
This product consists of two components: an emulsion and a color
paste. The main resin system is composed of epoxy resin, isocyanate
crosslinking agent, and toughening agent, which are neutralized
with acid to form the emulsion. The dispersion resin is epoxy
resin, and the color paste is prepared by grinding pigments and
fillers.
Features
Applications
Technical Specifications
Raw Paint Specifications
| Item | Technical Specifications | Inspection Standard | ||
| Emulsion | Color Paste | |||
| State of Material in Container | Milky white liquid | Black viscous liquid, no agglomeration | Visual inspection | |
| Solids Content | 120°C / 1h / 2g, % | 32-34 | 40-42 | GB/T1725-2007 |
| Fineness | μm | ≤10 | ≤20 | GB/T6753.1 |
| pH Value | 25°C | 6.2-6.8 | —— | GB/T9724 |
| Conductivity | 25°C, μs/cm | 1200-2200 | —— | HG/T3335 |
Bath Parameters
| Item | Technical Specification | Testing Standard | |
| Solids Content | 120°C / 1h / 2g, % | 16-18 | GB/T1725-2007 |
| pH Value | 25°C | 5.6-6.3 | GB/T9724 |
| Conductivity | 25°C, μs/cm | 1000-2200 | HG/T3335 |
| Throwing Power | cm, NV = 20% | ≥20 | HG/T3334-2012 |
| Application Temperature | °C | 28-32 | Thermometer |
| Electrophoresis Time | s | Full Immersion 60–180 | N/A |
| Application Voltage | V | 100-240 | 2L Bath Solution |
| Drying Time / Temperature | °C / min | 175/25 | GB/T1728 |
| Solvent Content | % | 1.0-2.5 | QB8008 |
| Breakdown Voltage | V | ≥300 | HG/T3952 |
| Ash Content | —— | 9-14 | GB/T1747-1979 |
| Coulombic Efficiency | mg/C | ≥25 | HG/T3952 |
Film Performance Indicators
| Item | Specification | Testing Standard | |
| Appearance | —— | Smooth, flat, no pinholes | Visual Inspection |
| Film Thickness | μm | 15-25 | GB/T13452.2 |
| Hardness | —— | ≥2H | GB/T6739 |
| Erichsen Cupping | mm | ≥10 | GB/T9753 |
| Adhesion | Grade | 0 | GB/T9286 |
| Flexibility | mm | 1 | GB/T1731 |
| Impact Resistance | cm | 50 | GB/T1732 |
| Gloss | 60° | 50-90 | GB/T9754 |
| Acid Resistance | 0.05mol/L H₂SO₄,48h | No peeling, blistering, or wrinkling; slight discoloration allowed | GB/T 9274 Method A |
| Alkali Resistance | 0.1mol/L NaOH,48h | No peeling, blistering, or wrinkling; slight discoloration allowed | GB/T 9274 Method A |
| Salt Spray Resistance | h | ≥800 | GB/T1771-2007 |
*Salt Spray Resistance: Using Bonderite standard phosphated steel panel, unidirectional corrosion ≤ 2 mm*
Bath Preparation
Color paste : Emulsion : Deionized water = 1:3:4 (by weight). Add
appropriate additives and neutralizing agents to adjust the
parameters. Let the mixture age for 48 hours, then filter and
apply.
Application Process
Pre-degreasing → Degreasing → Water Rinse → Surface Conditioning →
Phosphating → Water Rinse → Pure Water Rinse → Electrophoresis →
Post-rinse → Drying (Also suitable for silane or ceramic
pretreatment processes)
Packaging and Storage
Safety and Hygiene Regulations
|
