    Stainless Steel Checkered Plate 304 316L Anti-Slip 3mm-8mm

    Ask Lasest Price
    Brand Name : TISCO
    Model Number : 201 304 316L 2205 321.etc
    Certification : ISO
    Price : 2250 - 3150 USD/Ton
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    MOQ : 1 Ton
    • Product Details
    • Company Profile

    Stainless Steel Checkered Plate 304 316L Anti-Slip 3mm-8mm

    Stainless Steel Checker Plate ASTM EN DIN AISI304 AISI316L AISI321 SS Patterns Plate

    Products Specification

    Product NameStainless Steel checkered plate
    Thickness1mm-10mm
    Width1010,1219,1250,1500mm,etc.
    Length1000,2000,2440,2500,3000,5800,6000,or as your requirement.
    AuthenticationISO9001-2008,SGS.BV
    SurfaceTreatment2B NO.1
    Mainly Grade201 202 301 304 304L 309S 310S 316L 321 410 420 430 444 2205.etc
    ContactIf you have any question,please feel free to contact me. we are sure your inquiry or requirements will get prompt attention.

    Product Introduction​


    The Anti-Slip Stainless Steel Checkered Plate, available in thicknesses of 3mm, 4mm, 5mm, 6mm, and 8mm, is crafted from high-quality alloys 304 and 316L. Engineered with a distinctive checkered pattern, this plate significantly enhances traction, preventing slips and falls, making it an ideal choice for safety-critical environments. The combination of stainless steel's inherent durability and corrosion resistance with the anti-slip design ensures long-lasting performance, even in harsh and wet conditions.​

    Common Grades​

    • 304 Stainless Steel: A widely used austenitic grade, 304 offers excellent corrosion resistance in most general-purpose environments, including exposure to mild chemicals and atmospheric conditions. It provides good formability and weldability, making it suitable for various fabrication processes.​
    • 316L Stainless Steel: Recognized as a premium grade, 316L exhibits superior resistance to chloride-induced corrosion, such as in marine and chemical processing applications. The "L" denotes low carbon content, which minimizes the risk of intergranular corrosion during welding, ensuring consistent performance and reliability.​

    Standards Compliance​

    These checkered plates comply with international quality standards, including ASTM A653/A653M for steel sheet, metallic-coated by the hot-dip process, and EN 10088-2 for stainless steel flat products. These standards govern aspects such as chemical composition, mechanical properties (including tensile strength and yield strength), surface quality, and dimensional tolerances, ensuring uniformity and reliability across different batches and applications.​

    Advantages​

    1. Enhanced Safety: The checkered pattern creates a textured surface that provides excellent grip, reducing the likelihood of accidents in areas prone to moisture, oil, or foot traffic, like walkways, ramps, and platforms.​
    1. Corrosion Resistance: Both 304 and 316L alloys offer robust protection against rust and chemical attacks, extending the lifespan of the plates in diverse environments, from industrial settings to outdoor installations.​
    1. Versatility: Available in multiple thicknesses, these plates can be customized to meet different load-bearing requirements, from lightweight applications in architectural designs to heavy-duty usage in industrial flooring.​
    1. Easy Maintenance: The smooth stainless steel surface is easy to clean and sanitize, making it suitable for hygiene-sensitive areas such as food processing plants, hospitals, and kitchens.​
    1. Aesthetic Appeal: The distinctive checkered pattern adds a unique and modern look to any project, combining functionality with visual attractiveness for both indoor and outdoor applications.​

    Checkered Patterns​

    • Lug Pattern: Characterized by raised, rectangular lugs arranged in a grid, this pattern offers high traction in all directions. It is particularly effective in environments where heavy foot traffic or movement of wheeled equipment occurs.​
    • Diamond Pattern: The most common design, with intersecting diagonal lines forming diamond shapes. It provides balanced slip resistance and is often used in general-purpose applications, such as industrial flooring and vehicle platforms.​
    • Round Bar Pattern: Comprising parallel rows of round bars, this pattern offers a smoother surface while still providing sufficient grip. It is suitable for applications where a more refined appearance is desired without sacrificing safety.​

    Applications​

    Industrial Sector​

    • Factory Flooring: Used in manufacturing plants, warehouses, and workshops to create safe walking and working surfaces, especially in areas with heavy machinery, spills, or frequent movement of personnel and equipment.​
    • Stair Treads and Ramps: Provides reliable anti-slip protection for workers and visitors, reducing the risk of falls in industrial facilities with multiple levels.​
    • Tank and Vessel Walkways: Ensures secure access for maintenance and inspection in chemical processing plants and refineries, where exposure to corrosive substances is common.​

    Commercial and Public Spaces​

    • Shopping Malls and Airports: Installed in walkways, escalator landings, and other high-traffic areas to enhance safety for customers and visitors.​
    • Bridges and Overpasses: Offers durable, anti-slip surfaces that can withstand harsh weather conditions and heavy vehicle loads, ensuring the safety of pedestrians and motorists.​
    • Parking Garages: Helps prevent slips and falls on ramps and walkways, improving overall safety within the facility.​

    Marine and Transportation​

    • Ship Decks and Boat Docks: Resistant to saltwater corrosion and provides excellent traction, even when wet, ensuring the safety of crew and passengers on marine vessels.​
    • Truck and Trailer Flooring: Ideal for transporting goods, as the anti-slip surface prevents cargo from shifting during transit and provides secure footing for loading and unloading operations.​

    Architectural and Interior Design​

    • Balconies and Terraces: Adds both safety and aesthetic value to residential and commercial buildings, allowing for a modern and functional outdoor space.​
    • Interior Staircases: Creates a stylish and secure staircase solution, suitable for a variety of design themes, from contemporary to traditional.​

    Quality Assurance​

    Each checkered plate undergoes strict quality control processes, including chemical analysis, mechanical testing, and visual inspection. We provide comprehensive mill test reports and certifications to guarantee compliance with relevant standards and customer requirements. For customized orders, material traceability and specific performance specifications can be arranged. Contact us today to discuss your project needs and explore the best solutions for your anti-slip stainless steel checkered plate requirements.
