    48V 51.2V 100Ah 200Ah 300Ah 400Ah Options From 5kWh to 20kWh Lithium Lifepo4 Back Batteries Units

    Ask Lasest Price
    Brand Name : CTS
    Model Number : CTS-LR51100
    Certification : CE,MSDS,UN38.3
    Price : $600-1200
    Payment Terms : T/T,Western Union
    Supply Ability : 100000
    Delivery Time : 30-45 working days
    • Product Details
    • Company Profile

    48V 51.2V 100Ah 200Ah 300Ah 400Ah Options From 5kWh to 20kWh Lithium Lifepo4 Back Batteries Units

    Home Energy Storage System
    Engineered around premium Grade-A EV-standard LiFePO₄ cells, this battery module integrates an automotive-grade intelligent BMS with a precision solid-state circuit-breaker system for triple-layer protection—thermal, electrical, and mechanical. Designed for universal interoperability, it speaks the same protocols as the industry’s most popular hybrid and off-grid inverters (CAN, RS-485, Modbus-RTU) and can be soft-configured from 51.2 V to 48 V nominal at the press of a key. Scalability is built-in: up to eight identical units can be paralleled without additional combiner boxes, delivering a seamless 5 kWh to 40 kWh expansion path while maintaining ±2 % cell-level balancing accuracy and <100 ms fault isolation across the entire array.

















    Battery specification
    Model
    LW25200
    LW51100AH
    LW51100
    Basic parameter
    Battery Type
    LiFePo4
    LiFePo4
    LiFePo4
    Rated voltage
    25.6V
    51.2V
    51.2V
    Rated capacity
    200AH
    100AH
    200AH
    Energy(25°C, 0.5C)
    5.12kwh
    5.12kwh
    10.24kwh
    Size
    520*547*182mm
    520*547*182mm
    820*547*182mm
    weight
    55kg
    55kg
    105kg
    Electric parameter
    Voltage range
    22.4~28.8VDC
    44.8~57.6VDC
    44.8~57.6VDC
    Float charge voltage
    28V
    56V
    56V
    Max continue discharge current
    100A
    100A
    100A
    Pluse discharge current
    150A(1 Sec)
    150A(1 Sec)
    150A(1 Sec)
    Recommend discharge current
    ≤100A
    ≤50A
    ≤100A
    Max continue charge current
    50A
    50A
    50A
    Recommend charge current
    ≤60A
    ≤30A
    ≤60A
    cycle life(25°C, 0.5C,90%DOD)
    >6000 Cycles
    >6000 Cycles
    >6000 Cycles
    Design life
    >15years
    >15years
    >15years
    Terminal
    M8
    IP level
    IP20
    Max parallel number
    8pcs
    Safety standard
    IEC62619, UN38.3, MSDS
    communication function
    RS485/CAN(support inverter brand: Deye, Growatt, Luxpower,Solax, Victron, Goodwe, Sofar,SMA,Pylontec)
    BMS protection
    Over charge, over discharge, over temperature, over current,short circuit













    12+ years to sharpen a sword.
    We do only one thing, professional customization.
    20 + R&D team
    150 front-line production employees
    10 production lines
    20,000 square meter plant
    Capacity up to 500mwh

    Since 2011, CTS has focused on one-stop customization of lithium battery products such as electric vehicle batteries, large energy storage batteries, smart home storage batteries, high-end electric motorcycle batteries and so on. We have more 30 types of cells, and could make OEM battery pack from 12v-800v, 10-1000ah, which can be used in electric vehicle, E-bike, UPS, energy storage system, telecommunication base station,E-scooter, E-tools,unmanned airplane, golf cart, fork lift, cleaning car , electric
    wheelchair, etc. We has been pursuing quality policy of continuous innovation and improvement to meet customer's requirements. To realized full automation, we has introduced advanced foreign equipment and technology from Korea and Germany. To ensure the best quality, we has passed I S O 9 0 0 1 , I S O 1 4 0 0 1 and O H S A S 1 8 0 0 1 certifications. We stick to the company concept of human orientation and efficient innovation and we welcome customization. So, lets join together to promote the development of
    renewable energy and friendly environment.
