Model Number | ELl 1.38 | ELl 1.56 | ELl 1.95 | ELl 2.60 | ELl 3.91 |
| LED Type | SMD1010 | SMD1010 | SMD1212 | SMD1515 | SMD1515 |
| Pixel Pitch (mm) | 1.388 | 1.5625 | 1.953 | 2.604 | 3.906 |
| Panel Density (pixels/m²) | 518400 | 409600 | 262144 | 147456 | 65536 |
| Panel Resolution(pixels) | 360*360 | 320*320 | 256*256 | 192*192 | 128*128 |
| Panel Size (W*H*D/mm) | 500*500*75 |
| Power Supply | Dual |
| Power Weight(kg/panel) | ＜4kg |
| Module Quantity/Cabinet | 4 |
| Module Size (W*H/mm) | 250*250 |
| Brightness Max(cd/m²) | ＞1000 |
| Contrast Ratio | 4000:1 |
| Grey Scale | 16 bit |
| Refresh Rate | ＞3840 Hz |
| Frame Frequency | 30-70Hz |
| Colour Temperature(Calibrated) | 6500K |
| Colour Temperature (Adjustable Range) | 3500-9000K |
Viewing Angle,Horizontal /Vertical (deg) | H140/V140 deg |
| Working Voltage | 100-240V AC ,50/60Hz |
| Power Maximum Consumption (W/m²) | 800 |
| Power Aug Consumption(W/m²) | 200 |
| Operating Temperature/Humidity | -20 to 40 ℃ |
| Storage Temperature/Humidity | -35 to 60 ℃ |
| Cabinet Structure Material | Carbon Fibre |
| Service Ability | Front/Rear |
| Application Mode | Fixed |
| Installation Mode | Hanging,Standing,Wall Mounting |
| Lifetime (H) | 100 000 |
| Certificate | CE,FCC,ROHS |
| Protection | IP43 |
| Warranty | 2 year |
【Eye-Catching 】You don’t have to worry about it not being dazzling enough. It
adopts WIFI remote control programming technology, supports
barrier-free programming on mobile phones and computers within 30
feet. Supports text, date and time input and editing, and can set
more playback modes such as scrolling playback, flashing, and
static playback. A variety of colorful dynamic fonts, borders,
animated background settings, and continuous flashing lights can
create a strong visual impact , successfully helps you attract
widespread attention in various public places.
【Scrolling Full Color Led Sign】 Supports multi-picture and multi-video cycle playback, text,
picture, video and clock display on the same screen, multi-line
text input, scrolling playback and other playback methods,
specified time playback, countdown timer, vertical display,
multi-language, and timer on/off.
【Cutting-Edge LED Technology】Elevate your outdoor presence with our SMD technology-driven
full-color LED Sign. Seamlessly switch between vertical OPEN,
vertical LED SIGN,horizontal LED DISPLAY, and more. With a 10mm dot
distance and a vivid display resolution of W160 x H64 dots, this
sign is designed to captivate attention effectively. Illuminate
your message in vibrant hues, making it an irresistible focal point
for passersby.
