    GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable

    Ask Lasest Price
    Brand Name : PUNAISGD
    Model Number : GYXTW-8B1.3
    Certification : CE/ROHS/ISO9001
    Price : negociate
    Payment Terms : T/T,Western Union
    Supply Ability : 1000000km/month
    Delivery Time : 7days
    • Product Details
    • Company Profile

    GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable

    GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable

    Consider using GYXTC8Y for aerial jobs. Cable design makes installs simpler. Therefore, you benefit from fewer steps. Fiber counts vary across types. Observe the tensile capabilities closely. Besides, review the crush resistance data. Short-term tension reaches 2500 N. Long-term is rated at 1000 N.

    Next, operating temperature is -40°C to +70°C. Assess all local environmental factors. Confirm that the bending radius fits. Static bending minimum measures 10D. Thus, placement bending radius becomes 20D. GYXTC8Y offers water ingress defense. Design includes the messenger wire.

    The UV jacket adds longevity. Cable withstands harsh weather easily. Cable weight registers at 118 g/m. Gel cushioning provides safety.




    Thickness ( ±0.2)mm

    1.6

    Web

    Material

    PE

    Size ( ±0.5)mm

    2.0*3.0

    Messenger Wire

    Material

    Galvanized steel strand

    Size ( ±0. 1)mm

    R7×1.0

    Cable Diameter ( ±0.5)mm(W×H)

    9.0*14.5

    9.0*14.5

    9.6*15.2

    Cable Wetght ( ±10)kg/km

    150

    155

    168

    Allowable Tensile Strength(N)

    3000

    Allowable Crush Resistance(N/100mm)

    1000

    Application

    Aerial

    Attenuation

    1310nm

    ≤0.35dB/ km

    1550nm

    ≤0.21dB/ km

    Min. bending radius

    Without Tension

    10.0×Cable-φ

    Under Maximum Tension

    20.0×Cable-φ

    Temperature

    range (℃)

    Installation

    -20~+60

    Transport&Storage

    -40~+70

    Operation

    -40~+70
