Precast Concrete High Rib Lath Mesh Permanent Formwork System
| Attribute | Value |
|---|
| Name | Precast Concrete High Rib Lath Mesh Permanent Formwork System |
| Material | Galvanized steel |
| Size | 1.1m*3m or customized |
| Weight | 11kg/sqm |
| Rib lath | 0.4mm thickness |
| C-profiles | 0.6mm thickness |
| Connectors | 1.5mm thickness,20*19mm |
| Rebar | 5mm diameter, 700N /mm2 traction strength |
| Feature | long lasting, enhance strength, light weight, save time |
| MOQ | 1pcs |
Product Description
Hy rib mesh, also known as fast-ez high ribbed formwork, is
manufactured by punching and profiling galvanized steel sheet or
stainless steel sheet. It is a jointless steel mesh stiffened by
integral ribs. The continuous parallel V ribs are the main source
of the hy rib mesh. Meanwhile, the steel mesh can be curved along
the direction of V ribs. The profile of the steel mesh, in
combination with the hy-rib tangs, allow the hy rib mesh can be
widely used as the carrier of plaster, stucco and fireproofing
material and served as a permanent formwork for concrete.
Technical Specifications
| Material | Galvanized steel |
| Size | 1.1m*3m or customized |
| Weight | 11kg/sqm |
| Rib lath | 0.4mm thickness |
| C-profiles | 0.6mm thickness |
| Connectors | 1.5mm thickness,20*19mm |
| Rebar | 5mm diameter, 700N /mm2 traction strength |
Key Advantages
- Lightweight, easy to handle and install. It weights only one tenth
of the set-shaped steel formwork, which makes it easy to transport
and can be installed quickly.
- Easy to connect and shear. Multi-performance, easy to cut, and can
be bent and folded according to the required support shape.
- Good mechanical properties, low lateral pressure. The hollow-carved
mesh opening design allows the concrete pressure being reduced to
half of its original value, thus significantly reducing formwork
support.
Applications
- Plaster/Stucco Reinforcement: Used in walls, ceilings, and facades.
- Concrete Formwork: Reinforces thin-section concrete (e.g., prefab
panels, decorative elements).
- Tile Backing: Provides a stable base for tile adhesion in wet
areas.
- Repair Works: Strengthens patches in damaged concrete/plaster
surfaces.
Frequently Asked Questions
Q1: Can I get a free sample?
A: Yes, we have free samples to be provided anytime.
Q2: What type of materials do you use for your products?
A: Galvanized steel.
Q3: Is there quality control on all production lines?
A: Yes, all production line have adequate quality control.
Q4: What is your terms of payment?
A: T/T 30% as deposit, and 70% balance before delivery. We'll show
you the videos of products and packages before you pay the balance.
Q5: How about the delivery time?
A: Generally, it will take 15 days after receiving your advance
payment. The specific delivery time depends on the items and the
quantity of your order.
