    LG 15.4Inch automotive LCD Display model LA154WU1-SL01 1920*1200Pixels 6pin outdoor high brightness lcd panel

    Ask Lasest Price
    Brand Name : LG
    Model Number : LA154WU1-SL01
    Certification : Rohs,CE,FCC
    Price : $56
    Payment Terms : T/T,W, Western Union, MoneyGram
    Supply Ability : 2000pcs per week
    Delivery Time : 4-5 working day
    • Product Details
    • Company Profile

    LG 15.4Inch automotive LCD Display model LA154WU1-SL01 1920*1200Pixels 6pin outdoor high brightness lcd panel

    LG 15.4Inch automotive LCD Display model LA154WU1-SL01 1920*1200Pixels 6pin outdoor high brightness lcd panel


    LG Display Co., Ltd. (hereafter called LG Display) LA154WU1-SL01 (Alias: LA154WU1 (SL)(01)) is a 15.4 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -30 ~ 85°C , a storage temperature range of -40 ~ 95°C . It's general features are summarized by einklcd in the following: DCI-P3, sRGB, Wide Temperature, Hight Brightness, WLED Backlight, With LED Driver, Glossy , Interface: S-LVDS. Based on its features, einklcd recommend that this model be applied to Outdoor High Brightness, Automotive Display etc. According to the information stored in einklcd this model mass production on Q4, 2017, Now this model is discontinued. We inputted this model's specification on Mar 4 2019 for the first time, and the latest update on Feb 21 2023. If you want to embed LA154WU1-SL01 LCM in your future product, einklcd strongly recommend that you should contact with LG Display or it's distributor to learn lateast production and specification detail. The LA154WU1-SL01 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.


    Brand LG

    Display Model :P/NLA154WU1-SL01
    Diagonal Size: 15.4"

    Panel Type: a-Si TFT-LCD, LCM
    Resolution1920(RGB)×1200, WUXGA 147PPI Pixel

    Format RGB Vertical Stripe
    Active Area 330.624(W)×206.64(H) mm

    Bezel Opening-
    Outline (mm)341.2×219.14×13 (H×V×D)

    Treatment Glare (Haze 0%), Hard coating (3H)
    Luminance 800 cd/m² (Typ.)

    Contrast Ratio1450 : 1 (Typ.) (TM)
    Viewing Angle 89/89/89/89 (Min.)(CR≥10) Left / Right / Up / Down

    Response 10/8 (Typ.)(Tr/Td) ms
    Good View at Symmetry

    Work Mode IPS, Normally Black, Transmissive
    Color Depth16.7M 87% NTSC

    Back light WLED , 20K hours , With LED Driver
    Mass 830/850g (Typ./Max.)

    Used for: Outdoor High Brightness Automotive Display
    Refresh Rate 60Hz
    120Hz (60HZ Input) : Embedded MEMC Circuit
    120Hz+120Hz : 120Hz Panel+120Hz Backlight
    240Hz (60HZ Input) : Embedded MEMC CircuitTouchscreenWithout
    Signal Type SLVS (1 ch, 2 port) , Connector 6 pins
    Voltage Supply 12.0V (Typ.)
    Max. Ratings

    Storage Temp.: -40 ~ 95 °C

    Operating Temp.: -30 ~ 85 °C


    Quality LG 15.4Inch  automotive  LCD Display model LA154WU1-SL01 1920*1200Pixels 6pin outdoor high brightness lcd panel for sale
