WXWSCT-7 Water Cooled Split Unit 24000 BTU Ductless AC

    Buy cheap WXWSCT-7 Water Cooled Split Unit 24000 BTU Ductless AC from wholesalers

    Buy cheap WXWSCT-7 Water Cooled Split Unit 24000 BTU Ductless AC from wholesalers
    • Buy cheap WXWSCT-7 Water Cooled Split Unit 24000 BTU Ductless AC from wholesalers

    WXWSCT-7 Water Cooled Split Unit 24000 BTU Ductless AC

    Ask Lasest Price
    Brand Name : Weixuan
    Model Number : WXWSCT-7
    Certification : CE, ISO
    Price : negotiate
    Payment Terms : T/T,negotiate
    Supply Ability : 500pieces per month
    Delivery Time : 5-8days
    • Product Details
    • Company Profile

    WXWSCT-7 Water Cooled Split Unit 24000 BTU Ductless AC

    WXWSCT-7 Water Cooled Split Unit: 24,000 BTU Ductless Portable AC Solution


    The WXWSCT-7 Water Cooled Split Unit revolutionizes portable cooling with its innovative ductless design, delivering powerful 7KW (24,000 BTU) performance for industrial and commercial spaces. Unlike traditional air-cooled units that waste energy by exhausting indoor air, this split system transfers heat via a sealed water/glycol loop to an outdoor unit, preserving indoor air quality and slashing energy costs by 30%. Ideal for server rooms, kitchens, workshops, or temporary sites, it requires zero ductwork—simply connect the indoor and outdoor units with insulated hoses (max 20m) for instant cooling.

    Key Features & Advantages

    1. True Ductless Efficiency:

      • No window vents or complex installations.

      • Recirculates 100% indoor air, eliminating humidity loss and energy waste.

    2. Industrial-Grade Cooling:

      • 24,000 BTU capacity cools large spaces (up to 80m²) instantly.

      • Dual modes: Recirculation (air filtration) and Air-Conditioning (thermostat control from 8°C–35°C).

    3. Energy & Cost Savings:

      • Uses 4.5L water + 4.5L glycol mix for eco-friendly heat transfer.

      • Stepless fan control (1000–1500 m³/h) reduces noise (49 dB indoor).

    4. Flexible Deployment:

      • Outdoor unit handles 0°C–45°C temperatures; place it 20m away via lightweight hoses.

      • GMCC compressor and R32/R410A refrigerant ensure reliability.

    5. Smart Control:

      • LCD display with real-time diagnostics, thermostat, and alarm alerts.

    Technical Specifications

    Portable Water Cooling Unit

    Cooling Capacity

    KW

    7KW

    BTU

    24000BTU

    Power Supply

    V

    1PH,220V/50HZ

    Rated Power Input

    W

    2980W

    Rated Current Input

    A

    13A

    Indoor Unit Airflow

    Low

    1000m3/h

    Middle

    1200m3/h

    High

    1500m3/h

    Outdoor Unit Airflow

    M3/h

    4500m3/h

    Outdoor Working Temperature Range

    0~45

    Compressor Brand



    GMCC



    PA290G2CS-4MU1

    Cooling Media

    4.5L water/4.5L glycol

    Refrigerant Gas



    R32/R410A

    Net Weight

    Indoor

    L815*W360*H1200MM

    Outdoor

    L650*W320*H460MM

    Gross Weight

    Indoor

    114kg

    Outdoor

    25kg

    Noise Level

    Indoor

    49dB(A)

    Outdoor

    67dB(A)


    FAQ

    Q: How does this differ from standard portable ACs?
    A: Traditional units exhaust indoor air, reducing efficiency. The WXWSCT-7 uses a closed water-loop system, retaining cooled air and cutting energy use.

    Q: Is ductwork needed?
    A: No ducts required. Only two quick-connect hoses (included) link the indoor/outdoor units.

    Q: What’s the maximum hose length?
    A: Supports up to 20m total (5m or 15m hoses provided).

    Q: Can it cool a server room?
    A: Yes! Its 24,000 BTU output and precise thermostat (8°C–35°C) protect sensitive equipment.

    Q: How loud is the outdoor unit?
    A: 67 dB(A) (like a dishwasher). Position it remotely via hoses to minimize noise.
