Q355B Steel Structure Industrial Warehouse Hangar with High Strength Bolts

    Buy cheap Q355B Steel Structure Industrial Warehouse Hangar with High Strength Bolts from wholesalers

    Buy cheap Q355B Steel Structure Industrial Warehouse Hangar with High Strength Bolts from wholesalers
    • Buy cheap Q355B Steel Structure Industrial Warehouse Hangar with High Strength Bolts from wholesalers
    • Buy cheap Q355B Steel Structure Industrial Warehouse Hangar with High Strength Bolts from wholesalers
    • Buy cheap Q355B Steel Structure Industrial Warehouse Hangar with High Strength Bolts from wholesalers
    • Buy cheap Q355B Steel Structure Industrial Warehouse Hangar with High Strength Bolts from wholesalers
    • Buy cheap Q355B Steel Structure Industrial Warehouse Hangar with High Strength Bolts from wholesalers
    • Buy cheap Q355B Steel Structure Industrial Warehouse Hangar with High Strength Bolts from wholesalers

    Q355B Steel Structure Industrial Warehouse Hangar with High Strength Bolts

    Ask Lasest Price
    Brand Name : KXD
    Model Number : S-0084
    Certification : CE, ISO, SGS
    Price : US$ 50-80 per square meter
    Payment Terms : L/C,T/T
    Supply Ability : 3000 tons per month
    Delivery Time : 30-40 working days
    • Product Details
    • Company Profile

    Q355B Steel Structure Industrial Warehouse Hangar with High Strength Bolts

    Steel Structure Builing Specification:

    Steel Frame

    Materials

    Q355b (equivalent to S355JR, ASTM A572 Gr. 50)

    Q235b (equivalent to S235JR, ASTM A36)

    H section steel

    steel plate thickness: 8-30mm

    Welding

    Automatic submerged arc welding

    Rust removal

    Sand blasting

    Surface finish

    Alkyd / Epoxy zinc paint / hot dipping galvanized

    Connection

    By High strength bolt, Grade 10.9, Grade 8.8

    Supporting System

    Angle steel brace

    L steel, Q235b, painted / hot dipping galvanized

    Horizontal brace

    Steel bar, Q235b, painted / hot dipping galvanized

    Column brace

    Steel bar, Q235b, painted / hot dipping galvanized

    Tie beam

    CHS, Q235b, painted / hot dipping galvanized

    Connection

    By ordinary bolt, Grade 4.8

    Roof

    Purlin

    C/Z purlin, Q235b, pre-galvanized 100g-275g

    Roof panel

    Insulated sandwich panel or Corrugated steel sheet

    Edge cover

    steel sheet trimming

    Gutter

    Stainless steel / Galvanized sheet

    Down pipe

    Φ110 PVC-U, Φ150 PVC-U

    Fix Accessories

    sealing, self-tapping screws, etc.

    Walls

    Purlin

    C/Z purlin, Q235b, pre-galvanized 100g-275g

    Wall

    Insulated sandwich panel or corrugated steel sheet

    Accessories

    sealing, self-tapping screws, etc.

    Edge cover

    steel sheet trimming

    Fix Accessories

    sealing, self-tapping screws, etc.

    Door and window

    Different sizes and types are possible to custom.

    Additional option

    Skylight panel; Roof ventilator; Parapet; Glass curtain wall; Decorative aluminum panel

    Steel Structure Building's Advantages:


    Buildings’ structure Type

    Building service lifetime (years)

    Non-production processing building

    Production processing building

    Corrosive Production processing building

    Steel structure

    80

    70

    50

    Reinforced Concrete structure

    60

    50

    35

    Brick Concrete structure

    50

    40

    30

    Wood and Brick structure

    40

    30

    20

    Simple structure

    5-10


    Features of steel structure building

    1,Steel structure has light weight;

    2,Steel structure has good seismic and impact resistance;

    3,Steel structure manufacturing is highly industrialized;

    4,Steel structures can be assembled accurately and quickly;

    5,The building can be recycled after disassemble;

    6,Steel structure building construction period is short.


    KXD Company Service:

    Our service

    Design

    Large engineer team for quick response and quick quote

    Capability for elaborate design, high wind resistance performance

    Architecture Grade: I architect certificate

    Manufacture

    We can manufacture all kinds of steel structure products based on different conditions of projects.

    Workshop visit & Production Check

    Always warmly welcome to visit our production lines before the order, Project processing during the production and Finished steel components in the packing and loading.

    Certification and Test

    We accept your stage to supervise the whole fabrication, steel raw material testing, and also support third-party inspection.

    Installation

    We provide detailed drawings to ensure installation.

    We also provide remote guidance for installation.

    We can also send a team of engineers to guide or install on site.

    Quality inspection

    Factory Self-inspection

    Customer inspection

    Third party inspection


    KXD's Design Service:

    Details

    Architectural design to meet the required loads.

    1. Size (Length* Width* Height; Roof slope) : MOQ as 500sqm

    2. Different Structure Types to meet different demands:

    Single slope, Double slope, Multi slope

    Single span, Double span, Multi span

    Mezzanine, Single floor, Multi floors

    3. Base: Cement and Steel foundation bolts

    4. Column & Beam: Q345(S355JR) or Q235(S235JR) steel, all bolts connection!

    5. Bracing: X-type or V-type or other type bracing made from angle, round pipe, etc

    6. C or Z purlin: Size from C120~C320, Z100~Z200

    7. Roof and wall panel:

    Single steel sheet: thickness 0.4~0.7mm

    Sandwich panel: thickness 50mm~150mm

    8. Accessories: Semi-transparent skylight belts, Ventilators, down pipe, galvanized gutter, etc

    9. Surface treatment of steel:Alkyd / Epoxy zinc / Hot dipping galvanized

    10. Loading: Normally by 40'OT/ 40'HQ

    KXDs Packing & Loading Service:

    Normally for steel structure, we will pack them by the steel pallet. Packed processing outside of the loading container is easier to operate, easier to adjust and more efficient to use the container limited space. At the same time, steel pallet will also protect steel components to reduce the conflicts and surface coating abrasion.

    The steel pallet will be loaded by closed containers, like 20'GP, 40'HC.

    If clients wants to save the steel pallet cost, the steel components is better to be loaded into open top container one by one, like 40OT.

    Closed container:

    Advantage:Cheaper shipping cost,all members be packed together and reduce friction, the surface coating of steel members will be much better protected; easy unload

    Disadvantage:steel pallet cost

    Open top container:

    Advantage:easy to load &unload; save steel pallet cost

    Disadvantage:higher shipping cost, aleak and few quantity to load

    KXD is on-line for your any questions! Feel free to contact for your project! We will offer free architecture design for you.
