Original Vsol V1600GS 10GE PON Mini OLT 1 Port OLT GPON OLT
It is a box-type GPON OLT with one PON port (built in PON module), 2 1000M RJ45 uplink and 1 10G SFP+ uplink. The splitting ratio support maximum 1:128,maximum distance is 20KM. Its uplink and downlink bandwidth is as high as: 1.25Gbps/2.5Gbps.It can be widely used in FTTH, SOHO, small business office and other application scenarios..
The OLT integrates with network security, supports data, voice and video, and provides continuous forwarding, graceful
restarting and ring protection, improving the work efficiency and securing the maximum running time.
Small size and high density OLT, easy to install, convenient, flexible and easy to deploy high performance broadband
access network. It can be deployed in compact room environment, and can also be used for “Triple-Play” VPN, IP Camera, Enterprise LAN and ICT applications.
Feature:
High-Speed Fiber Optic Coverage
Gigabit optical fiber covers enterprise parks and the ultra-fast WiFi covers every corner.
Lightweight with High Performance
Easy Installation Saves Investment
Centralized Management and Plug & Play
POL Network of Small & Medium-sized Enterprises
Specification:
| Chassis | Rack | 1U |
|
GE/10GE
Uplink Port
| QTY | 3 |
| RJ45(GE) | 2 |
| SFP(GE)/SFP+(10GE) | 1 |
|
GPON Port Specification
| QTY | 1 |
| Fiber Type | 9/125μm SM |
| Connector | SC/UPC, Class C++/C+++ |
| GPON port speed | Upstream 1.244Gbps
Downstream 2.488Gbps |
| Wavelength | TX 1490nm, RX 1310nm |
| Max splitting ratio | 1:128 |
| Transmission Distance | 20KM |
| Management Ports | 1*CONSOLE port |
| Dimension (L*W*H) | 224mm*199mm*43.6mm |
| Weight | Net weight of single power: 1.07kg |
| Backplane Bandwidth (Gbps) | 16 |
| Port Forwarding Rate(Mpps) | 23.808 |
| Management Mode | Console/WEB/Telnet/CLI |
| Lightning
Protection Level | Power supply | 6KV |
| Device Interface | 4KV |
Application:
|
|
|
